Bently Nevada 172115-01 External Termination Block for 3500/65

Bently Nevada 172115-01 External Termination Block

Disponibilidad: 5 Quedan en stock

The Bently Nevada 172115-01 is a specialized External Termination Block (ETB) designed specifically for integration with the 3500/65 16-Channel Temperature...

Código: 172115-01

Manufacturer: Bently Nevada
Product No.: 172115-01
Product Type: External Termination Block
Product Origin: USA
Payment:T/T, Western Union
Weight: 50g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

The Bently Nevada 172115-01 is a specialized External Termination Block (ETB) designed specifically for integration with the 3500/65 16-Channel Temperature Monitor. This component serves as the critical physical interface between field-mounted sensors—such as RTDs and isolated tip thermocouples—and the 3500 series rack backplane. By relocating the termination point away from the monitor rack, this block facilitates cleaner cable management and simplifies maintenance procedures in high-density industrial monitoring installations.

Features

Designed for 16-channel high-density temperature monitoring applications.
Dedicated interface for RTD and isolated tip thermocouple field wiring.
Optimized for use with the 3500/65 Temperature Monitor system.
Facilitates organized field-to-rack wiring transitions.
Robust construction for demanding machinery protection environments.

Applications

Oil & Gas: Centrifugal compressors, pumps, and expanders.
Power Generation: Steam and gas turbines, generators, and transformers.
Industrial Manufacturing: Centrifugal separators, extruders, and heavy-duty reactor pumps.
General Rotating Machinery: Supporting temperature monitoring for critical assets.

Technical Specifications

Model Number	172115-01
Product Family	3500 Series
Common Mode Voltage	250V
Power Consumption	<1W
Operating Temperature	-40 degC to +85 degC
Storage Temperature	-40 degC to +85 degC
Humidity	Up to 95% non-condensing

Installation Guidelines

Ensure the 3500 rack system is powered down before installing or removing any I/O modules or associated termination blocks.
Terminate field-mounted RTD or isolated tip thermocouple wires directly into the provided Euro-style connectors on the 172115-01 block.
For 3-wire RTD configurations, ensure proper mapping to the designated A, B, and Common terminals.
Note that 4-wire RTD configurations require specific I/O module modifications (179952-01).
Maintain proper cable shielding and routing practices to minimize electromagnetic interference (EMI) in high-vibration industrial environments.

FAQ

What is the primary purpose of the 172115-01?

The 172115-01 acts as an external termination interface for the Bently Nevada 3500/65 16-Channel Temperature Monitor, allowing field sensors to connect to the rack system efficiently.

Does this block support different sensor types?

Yes, it is designed for use with 3-wire RTDs, 4-wire RTDs (with required modifications), and isolated tip thermocouples.

What type of connectors are utilized?

The block features Euro-style terminal connectors to ensure secure and reliable field wiring connections.
