Allen-Bradley 1769-IF4XOF2 Compact I/O Analog Combo Module

Availability: 99 left in stock

Product Overview The 1769-IF4XOF2 is a versatile analog combination module for CompactLogix and MicroLogix 1500 platforms. Designed as a cost-effective...

SKU: 1769-IF4XOF2

Manufacturer: Allen Bradley
Product No.: 1769-IF4XOF2
Product Type: Compact I/O Analog Combo Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 430g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The 1769-IF4XOF2 is a versatile analog combination module for CompactLogix and MicroLogix 1500 platforms. Designed as a cost-effective solution for non-critical process monitoring, it integrates both analog input and output capabilities into a compact footprint. It is suitable for applications where high-speed or high-precision measurements are secondary to space and budget constraints, such as basic temperature monitoring, level sensing, or speed reference control.

Technical Specifications

Item	Specification
Module Identifier	1769-IF4XOF2
I/O Configuration	4 analog inputs / 2 analog outputs
ADC Type	Successive
Resolution	8-bit (raw binary data)
Input Impedance	205 kΩ (voltage) / 150 Ω (current)
Output Load Range	>1 kΩ (voltage) / 0–300 Ω (current)
Backplane Current Draw	120 mA @ 5.1 V / 60 mA @ 24 V
Heat Dissipation	2.08 W maximum
Dimensions (W × H × D)	118 × 35 × 87 mm
Shipping Weight	0.43 kg

Signal Processing and Data Handling

The 1769-IF4XOF2 uses an 8-bit Successive Approximation register to convert analog signals into raw binary values. Data is stored as a byte in the controller’s I/O image.

Scaling Requirement: Apply scaling instructions in Studio 5000 or RSLogix to convert raw values to engineering units.
Accuracy Note: Intended for general-purpose variables. For 16-bit precision or high-speed loop control, consider dedicated 1769-IF4 or 1769-OF2 modules.
