AMM22-S3 YOKOGAWA CENTUM VP Datasheet & Technical Manual

AMM22-S3 YOKOGAWA CENTUM VP Analog Input Module

AMM22-S3 YOKOGAWA CENTUM VP Analog Input Module

Disponibilidad: 99 Quedan en stock

YOKOGAWA AMM22-S3 Analog Input Module Configured for high-density signal acquisition in CENTUM VP and CS distributed control systems, the YOKOGAWA...

Código: AMM22 S3

Manufacturer: Yokogawa
Product No.: AMM22 S3
Product Type: Analog Input Modules
Product Origin: Japan
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

YOKOGAWA AMM22-S3 Analog Input Module

Configured for high-density signal acquisition in CENTUM VP and CS distributed control systems, the YOKOGAWA AMM22-S3 (AMM22 Analog Input Module) provides direct physical execution of current and voltage loop monitoring.

Suffix Breakdown & Model Matrix

Model	Description
AMM22-S3	Standard 16-channel multi-signal analog input module

Hardware Specifications

Parameter	Specification
Model	AMM22-S3
Brand	YOKOGAWA
Origin	Japan
Weight	0.2 kg
Dimensions	12.7 cm x 2.5 cm x 20.3 cm
Operating Temp	-10 deg C to +55 deg C
Power Consumption	~2.5 W
Input Channels	16 (Non-isolated)
Input Impedance	250 Ohm (Current) / >= 1 MOhm (Voltage)
Sampling Rate	100 ms (Data Update Period)

DCS Process Control and Connectivity

The AMM22-S3 architecture utilizes a common-ground configuration across its 16 channels, facilitating the processing of 4-20 mA DC or 1-5 VDC signals. When integrating this module into a DCS platform, utilize 4-20 mA HART loop protocol considerations to ensure impedance matching at the 250 Ohm input stage. The module provides system-to-I/O bus isolation, though users must account for the non-isolated channel architecture when designing field-side loop power schemes to prevent common-mode noise propagation.

Frequently Asked Questions

Q: Does the AMM22-S3 support hot-swapping within the I/O nest?

A: The module is designed for rack-mounted installation. While the physical form factor allows for removal, verify system-level safety protocols regarding loop power before extraction to prevent open-circuit conditions that may trigger an automated burn-out alarm.

Q: How should I configure burn-out detection for mixed signal loops?

A: Burn-out detection is software-configurable per channel. Set the threshold to upscale or downscale based on the specific requirements of the connected field transmitter to distinguish between valid 4 mA minimum signals and actual loop wire breakage.

Field Installation Guidelines

Mounting: Secure the module within the designated rack-mounted I/O cabinet. Ensure the backplane interface is seated correctly to maintain stable communication with the central controller.
Grounding: As a non-isolated channel module, verify that all field signals share a consistent reference potential. Terminate cable shields at the cabinet ground bar to mitigate electromagnetic interference, ensuring that the shield does not become a path for return current.
Wiring: Maintain strict separation between high-voltage power conduits and analog input cabling. Use twisted-pair shielded cables to optimize the 12-bit resolution of the input data and prevent cross-channel noise induction.
