140CPU11302 Schneider Electric Modicon Quantum Processor

Availability: 94 left in stock

Product Description The 140CPU11302 is a legacy CPU module for the Schneider Electric Modicon Quantum platform. Based on an Intel 80486 microprocessor, it provides reliable deterministic control...

SKU: 140CPU11302

Manufacturer: Schneider
Product No.: 140CPU11302
Product Type: Modicon Quantum Processor
Product Origin: France
Payment:T/T, Western Union
Weight: 440g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Description

The 140CPU11302 is a legacy CPU module for the Schneider Electric Modicon Quantum platform. Based on an Intel 80486 microprocessor, it provides reliable deterministic control for mid-range industrial applications, particularly for Concept and ProWORX 32 environments. It manages discrete and analog I/O, communicates via the Quantum backplane, and supports Modbus and Modbus Plus networking.

Technical Specifications

Item	Specification
Microprocessor	Intel 80486
Clock Speed	20 MHz
User Memory	256 KB RAM
Register Capacity	Up to 50k words
Maximum Discrete I/O	8192 In / 8192 Out
Maximum Analog I/O	1024 In / 1024 Out
Communication Ports	1 × Modbus (RS-232), 1 × Modbus Plus (DB9), 1 × Executive Port
Programming Software	Concept, ProWORX 32, Modsoft
Power Requirements	750 mA @ 5 V DC
Slot Occupancy	1 Quantum slot
Watchdog Timer	250 ms (hardware)
Real-Time Clock	Built-in with battery backup
Battery	3V Lithium (990XCP98000, sold separately)

Typical Applications

Legacy manufacturing plants using Modicon Quantum
Utility substations with Modbus Plus token-ring networks
Replacement/maintenance for existing 140-series automation systems

Notes

Memory: 256 KB RAM; verify program size fits before replacement
Battery: Required for RTC and data retention; sold separately
Optimized for stability and deterministic execution rather than high-speed modern networking
