ABB 07AI91 GJR5251600R0202 Analog I/O Module

ABB 07AI91 GJR5251600R0202 Advant Controller 31 Analog I/O Module

Disponibilidad: 8 Quedan en stock

The ABB 07AI91 (GJR5251600R0202) is a high-performance analog I/O module designed for the Advant Controller 31 (AC31) system. This versatile...

Código: GJR5251600R0202

Manufacturer: ABB
Product No.: GJR5251600R0202
Product Type: Analog I/O Module
Product Origin: Sweden
Payment:T/T, Western Union
Weight: 360g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

The ABB 07AI91 (GJR5251600R0202) is a high-performance analog I/O module designed for the Advant Controller 31 (AC31) system. This versatile unit is engineered to support a wide range of process signals, providing reliable data acquisition in demanding industrial automation environments.

Features

Supports 8 differential or 16 single-ended analog input channels.
Flexible configuration for voltage (U), current (I), and RTD sensor inputs.
Compatible with 1-wire and 3-wire connection schemes.
High-resolution conversion with 12-bit plus sign capability for precise monitoring.
Integrated 1500V AC channel-to-bus isolation for enhanced electrical protection.
Optimized for standard 24V DC control power systems.

Technical Specifications

Model	07AI91 (GJR5251600R0202)
Supply Voltage	24V DC +/- 10%
Power Consumption	3.2W typical
Channels	8 differential / 16 single-ended
Input Ranges	0-20mA, 4-20mA, U/I/RTD
Resolution	12-bit + sign
Accuracy	+/- 0.1% of span (at 25 degC)
Operating Temperature	-25 degC to +60 degC
Storage Temperature	-40 degC to +85 degC
Humidity	5-95% RH (non-condensing)

Installation Guidelines

Ensure the controller power is disconnected before installing or removing the module from the rack.
Mount the module in a clean, dry environment with adequate ventilation to prevent overheating.
Use shielded cables for all analog signal connections to minimize electromagnetic interference (EMI).
Maintain proper grounding practices to ensure signal integrity and protect against surges.
Handle the module using ESD-safe procedures to prevent damage to internal electronic components.

FAQ

What is the primary function of the 07AI91 module?
The 07AI91 is an analog input module for the ABB AC31 series, used to interface various sensors and transmitters, including current, voltage, and temperature (RTD) inputs, into the control system.

Can this module handle 3-wire RTD sensors?
Yes, the module is designed to support both 1-wire and 3-wire connection configurations for flexible sensor integration.

What is the required power supply for this unit?
The module operates on a 24V DC supply with a tolerance of +/- 10%.
