IC695ETM001 GE RX3i Ethernet Module

IC695ETM001 RX3i PACSystems Ethernet Interface Module | GE Fanuc

IC695ETM001 RX3i PACSystems Ethernet Interface Module | GE Fanuc

Disponibilidad: 10 Quedan en stock

The GE IC695ETM001, also cataloged as the IC695ETM001 Ethernet Interface Module, operates as a dedicated hardware component for network communication...

Código: IC695ETM001

Manufacturer: GE Fanuc
Product No.: IC695ETM001
Product Type: Ethernet Interface Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

The GE IC695ETM001, also cataloged as the IC695ETM001 Ethernet Interface Module, operates as a dedicated hardware component for network communication and data routing within RX3i PACSystems platforms. The single-slot interface installs into an RX3i chassis to facilitate high-speed data exchanges between the host processor and peripheral control networks via standardized industrial protocols.

Hardware Specifications

Parameter	Specification
Model	IC695ETM001
Brand	GE Fanuc Emerson
Origin	USA
Weight	0.45 kg (1.00 lbs)
Dimensions	Single-slot RX3i chassis profile
Operating Temp	0 to 60 deg C
Power Consumption	Standard backplane power allocation
Ethernet Interface	2x 10/100 Mbps autosensing ports
Ethernet Connectors	8-pin female shielded RJ45
Serial Interface	1x RS-232 port
Serial Connector	9-pin female D-connector
Serial Baud Rates	1200 bps to 115200 bps
Processor Speed	200 MHz Ethernet processor
Communication Modes	Half and full duplex
Multi-node Topology	Supports network daisy-chaining
Substrate Compatibility	IC695CHS007, IC695CHS012, IC695CHS016

Industrial Control and Network Determinism

The IC695ETM001 interfaces directly via Profinet / EtherNet/IP deterministic networks and associated TCP/IP protocol layers to maintain synchronized processing arrays without transaction lag. Through native EGD, Modbus TCP, and SRTP structures, the unit controls deterministic I/O density scaling profiles while minimizing transmission jitter across decentralized architecture nodes. Firmware flash compatibility ensures structured access to the integrated Station Manager diagnostic interface over the serial or Ethernet bus, supporting precise timestamp alignment via SNTP time server routines.

Frequently Asked Questions

Q: What are the specific firmware and environment requirements to execute a hot-swap operation?

A: The IC695ETM001 supports hot-swapping (insertion or extraction under backplane power) even while the host processor resides in RUN mode, provided that the system components maintain firmware revision 2.51 or higher.

Q: Which RX3i modules or processors are incompatible with this communication interface?

A: The module is compatible with standard RX3i hardware configurations, with the explicit exception of the CPE400 controller, which does not support the direct physical backplane bus interfaces of this card.

Field Installation Guidelines

Network Topology and Cable Routing: Connect the two shielded RJ45 interfaces into star, line, or daisy-chain layouts. Route the Category 5e/6 industrial Ethernet runs isolated from three-phase AC power lines to suppress electromagnetic interference.
Shield Grounding Matrix: Ensure the metal shielding on the 8-pin female RJ45 plug establishes positive physical contact with the module housing ground frame to prevent common-mode noise from corrupting data frames.
Serial Diagnostic Configuration: When interfacing with the 9-pin female D-connector for Station Manager supervisory tasks, verify that cable distances match standard RS-232 limits and baud rates align with the 1200 bps to 115200 bps baseline.
