Allen-Bradley 1756-DMD30 ControlLogix 1-Axis Drive Module

Allen-Bradley 1756-DMD30 ControlLogix 1-Axis Drive Control Module

Disponibilidad: 6 Quedan en stock

DescriptionThe Allen-Bradley 1756-DMD30 is a dedicated single-axis drive control module designed for integration within the ControlLogix platform. This module enables...

Código: 1756-DMD30

Manufacturer: Allen-Bradley
Product No.: 1756-DMD30
Product Type: Drive Control Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 250g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

Description

The Allen-Bradley 1756-DMD30 is a dedicated single-axis drive control module designed for integration within the ControlLogix platform. This module enables precise motion control and communication between the ControlLogix controller and supported drive systems, utilizing fiber optic connectivity for robust data exchange in industrial environments.

Features

Provides high-speed, single-axis drive control capabilities.
Integrated LED status indicators for real-time diagnostic monitoring.
Utilizes fiber optic interface for reliable communication.
Compact module design for standard ControlLogix chassis mounting.
Optimized for low power dissipation and efficient thermal management.

Technical Specifications

Model Number	1756-DMD30
Control Axis	1-Axis
Power Consumption	1.35 Amps at 5.1 VDC
Peak Power Dissipation	6.96 Watts
Thermal Dissipation	23.7 BTU/hr
Operating Temperature	0 to 60 degC (32 to 140 degF)
Storage Temperature	-40 to 85 degC (-40 to 185 degF)
Input Voltage	24 VDC

Installation Guidelines

Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-DMD30 module to prevent electrical damage.
Verify that the module is fully seated in the chassis slot and the locking tabs are engaged.
Follow proper ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive internal circuitry.
Maintain adequate ventilation around the chassis to ensure operating temperatures remain within the specified 0 to 60 degC range.
Route fiber optic cables away from high-voltage wiring and sources of electromagnetic interference (EMI) to maintain signal integrity.

FAQ

What is the primary function of the 1756-DMD30?

The 1756-DMD30 is a ControlLogix module used for controlling a single axis of motion in a drive system, facilitating communication through fiber optic links.

Does this module require external power?

The module operates on 24 VDC and consumes 1.35 Amps at 5.1 VDC from the backplane; ensure your power supply budget accounts for these requirements.

What are the storage requirements for this module?

The unit should be stored in a controlled environment between -40 and 85 degC (-40 to 185 degF) to ensure long-term reliability.
