Woodward 5466-253 Rev H MicroNet Analog Combo TMR Module

The 5466-253 (Model: 5466-253) is a high-density, multi-function I/O module engineered for Woodward’s MicroNet and MicroNet Plus control systems. As an "Analog Combo" board, it integrates analog inputs, analog outputs, speed sensing, and actuator driver circuits into a single hardware platform. This specialized 5466-253 (Part Number: 5466-253) is designed for Triple Modular Redundant (TMR) architectures, providing the fault-tolerant processing required for critical turbine governors and emergency shutdown systems.

Operating on the MicroNet HD (High Density) platform, the 5466-253 (Model: 5466-253) Revision H features enhanced signal processing algorithms that reduce noise interference in high-vibration turbine environments. By consolidating multiple I/O types—including high-resolution speed inputs for magnetic pickups—this module significantly reduces rack space requirements and wiring complexity. Its built-in diagnostic suite monitors loop integrity and internal power rail health, ensuring that any hardware anomaly is reported to the central CPU before it impacts process safety.

Detailed Technical Specifications

The 5466-253 (Model: 5466-253) is optimized for high-speed deterministic control in power generation and mechanical drive applications.

Feature	Details
Manufacturer	Woodward
Model Number	5466-253
Revision	Rev H (Hardware Revision)
System Platform	MicroNet / MicroNet Plus / MicroNet HD
I/O Type	Analog Combo TMR (Triple Modular Redundant)
Analog Inputs	8 Channels (Software selectable: 0–5 V or 4–20 mA)
Analog Outputs	4 Channels (4–20 mA, 12-bit resolution)
Speed Inputs	4 High-resolution channels (MPU or Proximity)
Actuator Outputs	2 Proportional driver channels
Input Voltage	24 VDC nominal (system backplane powered)
Operating Temp	-20°C to +70°C
Isolation	Channel-to-channel and channel-to-bus galvanic isolation
Weight	1.85 lbs (0.84 kg)
