General Electric IC698PSA100 RX7i Power Supply Module

General Electric IC698PSA100 PACSystems RX7i Power Supply Module

Disponibilidad: 2 Quedan en stock

The General Electric IC698PSA100 is a high-performance power supply module engineered for the PACSystems RX7i control platform. This module is...

Código: IC698PSA100

Manufacturer: General Electric
Product No.: IC698PSA100
Product Type: Power Supply Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1920g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

The General Electric IC698PSA100 is a high-performance power supply module engineered for the PACSystems RX7i control platform. This module is designed to provide stable, reliable power to the backplane, supporting a wide range of input voltages to accommodate diverse industrial environments.

Features

Designed for dedicated use in Slot 0 of the RX7i rack system.
Supports universal AC input (85 to 264 VAC) and DC input (100 to 150 VDC).
Provides triple output voltages: 5.1 VDC, +12 VDC, and -12 VDC.
Integrated protection mechanisms against overvoltage and overcurrent conditions.
High power factor efficiency (0.99 minimum) to ensure stable power delivery.
Includes a 15 ms ride-through time to maintain operations during brief power fluctuations.

Applications

This power supply is intended for use in GE PACSystems RX7i automation systems. It is commonly deployed in large-scale industrial control architectures, including power generation, water treatment, and manufacturing process control, where consistent power delivery is critical for system reliability.

Technical Specifications

Model Number	IC698PSA100
Input Voltage Range	85-264 VAC / 100-150 VDC
Total Output Power	100 Watts
Output Current (5.1 VDC)	0-20 Amperes
Output Current (+12 VDC)	0-2 Amperes
Output Current (-12 VDC)	0-1 Ampere
Operating Temperature	0 to 60 degC
Isolation	1500 Volts
Input Power (Typical)	125 Watts

Installation Guidelines

Slot Placement: The IC698PSA100 must be installed in the leftmost slot (Slot 0) of the RX7i backplane.
Wiring: Use AWG #16 (1.3 mm2) for input power connections and AWG #12 (3.3 mm2) for the ground terminal to ensure safety and compliance.
Safety: Always disconnect the main power source before installing or removing the module from the rack to prevent electrical shock or damage to the backplane pins.
Environment: Ensure adequate clearance in the cabinet for ventilation to maintain the operating temperature between 0 and 60 degC.

FAQ

Q: What is the primary function of the IC698PSA100?
A: It is a dedicated power supply module that converts AC or DC line power into the regulated DC voltages required by the RX7i system components.

Q: Can this module be used in any slot of the RX7i rack?
A: No, this power supply is specifically designed to be mounted in the leftmost slot (Slot 0) of the RX7i chassis.
