Woodward 5136-DNP-CPCI SST DeviceNet Interface Card

التوفر: 7 متوفر في المخزون

DescriptionThe Woodward 5136-DNP-CPCI is a high-performance SST DeviceNet interface card engineered for CompactPCI (cPCI) industrial bus architectures. This communication module...

رمز المنتج: 5136-DNP-CPCI

Manufacturer: Woodward
Product No.: 5136-DNP-CPCI
Product Type: DeviceNet Interface Card
Product Origin: USA
Payment:T/T, Western Union
Weight: 150g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

Description

The Woodward 5136-DNP-CPCI is a high-performance SST DeviceNet interface card engineered for CompactPCI (cPCI) industrial bus architectures. This communication module facilitates seamless integration between host controllers and DeviceNet networks, enabling the exchange of real-time I/O data and explicit messaging. By offloading complex protocol management from the main system CPU, the 5136-DNP-CPCI ensures superior network performance, reduced communication latency, and enhanced system stability in mission-critical automation environments.

Features

CompactPCI (cPCI) form factor for secure mechanical fit and high-speed backplane connectivity.
Supports DeviceNet Master and Slave configurations as a Group 2 Client/Server.
Onboard processor manages the DeviceNet stack, supporting Polled, Cyclic, and Change-of-State (COS) connections.
Data transmission rates selectable at 125, 250, or 500 kbps.
Integrated 500 VDC optical isolation to protect host systems from fieldbus voltage surges and ground loops.
Onboard status LEDs for real-time diagnostics of bus power and network health.

Applications

This interface card is primarily utilized in turbine control systems, automotive assembly lines, and heavy industrial processing plants where deterministic, high-speed fieldbus communication is required to minimize downtime.

Technical Specifications

Model	5136-DNP-CPCI
Brand	Woodward (SST)
Bus Interface	CompactPCI (cPCI)
Network Protocol	DeviceNet
Data Rates	125, 250, 500 kbps
Isolation	500 VDC Optical
Operating Temperature	0 to 60 deg C

Installation Guidelines

Ensure the host system is powered down before inserting or removing the 5136-DNP-CPCI module into the cPCI backplane.
Handle the card by its edges and utilize ESD-safe practices to prevent damage to sensitive electronic components.
Ensure the module is fully seated in the cPCI slot and the front panel screws are tightened to provide proper grounding and mechanical stability.
Route DeviceNet fieldbus cabling away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
Verify bus power and network termination settings according to the DeviceNet physical layer requirements.

FAQ

What is the primary function of the 5136-DNP-CPCI?

The 5136-DNP-CPCI acts as a communication bridge, allowing a host controller on a CompactPCI bus to communicate with devices on a DeviceNet network by handling the protocol stack independently.

Does this card support both Master and Slave modes?

Yes, the module is designed to operate as a Group 2 Client/Server, supporting both Master and Slave configurations for flexible network integration.

What is the purpose of the optical isolation?

The 500 VDC optical isolation provides a safety barrier between the industrial DeviceNet fieldbus and the host system, protecting the controller from electrical surges or ground loop issues originating in the field.
