Schneider Electric TSXDSZ32R5 Relay Output Module

Disponibilidad: 7 Quedan en stock

The Schneider Electric TSXDSZ32R5 is a specialized relay output module designed for use within the Modicon TSX Micro PLC platform....

Código: TSXDSZ32R5

Manufacturer: Schneider Electric
Product No.: TSXDSZ32R5
Product Type: Relay Output Module
Product Origin: France
Payment:T/T, Western Union
Weight: 520g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

The Schneider Electric TSXDSZ32R5 is a specialized relay output module designed for use within the Modicon TSX Micro PLC platform. This module provides reliable switching capabilities for industrial control applications, offering 32 output channels suitable for handling various field devices. Although the manufacturer discontinued this product in 2020, it remains a critical component for the maintenance and support of legacy TSX Micro automation systems.

Features

32-point relay output configuration for versatile load control.
Wide operating voltage range from 24 VAC to 240 VAC.
Designed for integration with the Modicon TSX Micro programmable controller series.
Fast response time of less than 10 ms for real-time control requirements.
Robust isolation voltage of 1500 V for 1 second to ensure system safety and signal integrity.

Technical Specifications

Model Number	TSXDSZ32R5
Manufacturer	Schneider Electric
Product Type	Relay Output Module
Number of Outputs	32
Voltage Range	24 - 240 VAC
Response Time	< 10 ms
Current Consumption	175 mA
Power Dissipation	3.5 W
Isolation Voltage	1500 V (1 s)
Insulation Resistance	>= 10 mOhm

Installation Guidelines

Ensure the PLC system is powered down before installing or removing the module to prevent electrical damage or unexpected system behavior.
Verify that the module is correctly seated in the TSX Micro rack and that all locking mechanisms are engaged.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive internal circuitry.
Ensure field wiring is properly routed away from high-voltage power cables to minimize electromagnetic interference (EMI).
Verify that the load connected to the relay outputs does not exceed the specified current and voltage ratings to prevent relay contact degradation.

FAQ

Is the TSXDSZ32R5 still in production? No, this module was officially discontinued by Schneider Electric in 2020. It is now typically sourced as a spare part for existing installations.

What is the primary function of this module? The TSXDSZ32R5 is a digital output module that uses physical relays to switch external devices, providing electrical isolation between the PLC logic and the field equipment.
