Honeywell 8C-TDODB1 51307151-175 Digital Output Module

Availability: 4 left in stock

The Honeywell Experion LX 8C-TDODB1 (51307151-175) is a high-density digital output module designed for reliable signal control in industrial automation...

SKU: 8C-TDODB1

Manufacturer: Honeywell
Product No.: 8C-TDODB1
Product Type: Digital Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 240g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Honeywell Experion LX 8C-TDODB1 (51307151-175) is a high-density digital output module designed for reliable signal control in industrial automation systems. This module features 32 source-type output channels, providing robust performance for 24 VDC control applications.

Features

32-channel source-type digital output configuration.
Standard 24 VDC operating voltage for compatibility with Experion LX control architectures.
Galvanic isolation rated at 1000 VAC RMS or 1500 VDC to ensure signal integrity and protection.
High-density design optimized for space-efficient cabinet mounting.
Low off-state leakage current of 5 µA (max) for improved switching precision.

Technical Specifications

Model Number	8C-TDODB1 (51307151-175)
Output Channels	32
Output Type	Source
Voltage Rating	24 VDC
Load Voltage	30 VDC (Max)
Load Current	100mA per channel / 3.2A per module (Max)
Turn-On/Off Time	10 ms (Max)
Galvanic Isolation	1000 VAC RMS / 1500 VDC

Installation Guidelines

Ensure the control system power is disconnected before installing or removing the module from the rack.
Use appropriate ESD protection when handling the module to prevent damage to internal circuitry.
Verify that the field wiring conforms to the voltage and current specifications to avoid thermal overload.
Ensure proper grounding of the I/O backplane to maintain the integrity of the galvanic isolation.
Route signal wiring away from high-voltage AC cables to minimize electromagnetic interference (EMI).

FAQ

What is the primary function of the 8C-TDODB1 module?
This module serves as a digital output interface for the Honeywell Experion LX system, allowing the controller to drive external field devices using 32 independent source-type output channels.

Is this module compatible with other Experion series?
The 8C-TDODB1 is specifically engineered for the Experion LX series. Please verify your system hardware revision and documentation before integration.
