Honeywell CC-TDIL11 51308388-175 Digital Input Module

Honeywell CC-TDIL11 51308388-175 32-Channel Digital Input Module

Availability: 2 left in stock

DescriptionThe Honeywell CC-TDIL11 (51308388-175) is a high-density, 32-channel digital input module designed for integration within the Experion PKS distributed control...

SKU: CC-TDIL11

Manufacturer: Honeywell
Product No.: CC-TDIL11
Product Type: Digital Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 460g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Honeywell CC-TDIL11 (51308388-175) is a high-density, 32-channel digital input module designed for integration within the Experion PKS distributed control system. This module facilitates reliable data acquisition from field devices, providing galvanic isolation and advanced diagnostic capabilities to ensure signal integrity across the process control environment.

Features

32 discrete input channels for high-density field signal monitoring.
Galvanic isolation rated at 1500 VAC RMS or ±1500 VDC to protect system electronics from field-side transients.
Integrated open wire detection for proactive maintenance and fault identification.
Supports optional redundancy configurations to increase system availability.
Flexible field power selection, allowing for either internal or external power source configurations.
Supplies non-incendive field power for hazardous area compatibility.
Direct and reverse input status indication for simplified troubleshooting.

Technical Specifications

Model Number	CC-TDIL11 (51308388-175)
Input Channels	32
Isolation Type	Optical (within IOM)
Isolation Rating	1500 VAC RMS / ±1500 VDC
Input Voltage Range	18 to 30 VDC
ON Sense Threshold	13 VDC (min) / 3 mA (min)
OFF Sense Threshold	5 VDC (max) / 1.2 mA (max)

Installation Guidelines

Ensure the system power is completely disconnected before inserting or removing the module from the I/O rack.
Verify that the module is correctly seated in the assigned slot to establish a secure connection to the backplane.
Use shielded cables for field wiring to minimize electromagnetic interference (EMI) and crosstalk.
Maintain proper grounding practices for the I/O rack to ensure effective common-mode noise rejection.
Ensure that the field power supply is correctly configured for internal or external operation as required by the specific application loop.
Handle the module using standard ESD-safe practices to prevent damage to internal components.

FAQ

Does this module support redundant operation?

Yes, the CC-TDIL11 is designed to support optional redundancy, which enhances system reliability by allowing a backup module to take over in the event of a primary module failure.

What is the primary function of the internal diagnostics?

The internal diagnostics provide continuous monitoring of data integrity and field signal status, including the ability to detect open wire conditions, which helps operators identify and resolve field faults rapidly.
