Honeywell CC-PWRR01 Redundant Power Supply System

Availability: 7 left in stock

DescriptionThe Honeywell CC-PWRR01 is a high-reliability redundant power supply system designed for demanding DCS (Distributed Control System) environments. This 20A...

SKU: CC-PWRR01

Manufacturer: Honeywell
Product No.: CC-PWRR01
Product Type: Power Supply Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 4500g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Honeywell CC-PWRR01 is a high-reliability redundant power supply system designed for demanding DCS (Distributed Control System) environments. This 20A power system ensures continuous operation by utilizing dual power supply modules, providing a stable 24-26VDC output to critical control hardware. The assembly is engineered to support seamless switchover during power events, maintaining system integrity in industrial automation applications.

Features

Redundant configuration utilizing dual power supplies for high availability.
Supports a wide AC input range of 100-230 VAC.
Designed for 20A total system load capacity.
Includes integrated power adapter boards and rack TDI power transistors.
Provides a 20ms holdup time to buffer against transient power interruptions.
Battery backup capability providing up to 30 minutes of runtime at 20A maximum load.

Included Components

2x 51202343-001 Indication Cable
2x 51199935-100 Power Adapter Board
4x 51198685-100 (SPS5710-2-LF) Power Supply Module
2x 51199930-100 (SPS5713) Rack TDI Power Transistor

Technical Specifications

Parameter	Specification
Model	CC-PWRR01
Input Voltage	100-230 VAC
Frequency	47-63 Hz
Output Voltage	24-26 VDC
Holdup Time	20 ms
Load Change Range	30% to 100%
Efficiency	65% (minimum)
Tariff Code	8537101190

Installation Guidelines

Ensure the rack mounting environment is free from excessive dust, moisture, and corrosive gases.
Verify that the AC input source is stable and correctly phased before connection.
Use appropriate shielded cabling for all signal and power connections to minimize EMI susceptibility.
Ensure adequate ventilation around the power supply modules to maintain operating temperatures within specified limits.
Always power down the system and disconnect the AC mains before installing or removing any modules from the rack.
Ground the chassis according to local electrical codes to prevent ground loops and ensure safety.

FAQ

Q: What is the primary function of the CC-PWRR01?
A: It acts as a redundant power supply system for Honeywell DCS equipment, ensuring that the control system remains powered even if one supply module fails.

Q: Does this unit include the necessary cabling for integration?
A: Yes, the system includes the required indication cables and power adapter boards as specified in the included components list.
