Honeywell MC-TPIX12 51304084-175 Pulse Input Module

Availability: 5 left in stock

DescriptionThe Honeywell MC-TPIX12 (51304084-175) is a specialized Pulse Input Module designed for the Fault Tolerant Control (FSC) system. This module...

SKU: MC-TPIX12

Manufacturer: Honeywell
Product No.: MC-TPIX12
Product Type: Pulse Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 740g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Honeywell MC-TPIX12 (51304084-175) is a specialized Pulse Input Module designed for the Fault Tolerant Control (FSC) system. This module serves as a Pulse Input Field Termination Assembly (FTA), engineered to interface with field devices to monitor and process pulse-based signals. It is built to meet rigorous industrial standards, featuring conformal coating for enhanced protection in demanding environments and full CE compliance.

Features

8 dedicated pulse input channels for high-density signal monitoring.
Compatible for use with IOP modules MU-PPIX02 or MC-PPIX02.
Conformally coated circuitry to resist environmental degradation.
High-precision rate measurement with a resolution of ±0.4 Hz.
Robust input protection rated for up to ±30 V without damage.

Applications

This module is typically deployed in critical process control applications where precise frequency or pulse counting is required, such as turbine speed monitoring, flow meter integration, and rotational equipment diagnostics within the Honeywell FSC architecture.

Technical Specifications

Model	MC-TPIX12 (51304084-175)
Input Points	8
Input Impedance	10 kOhm minimum
PV Update Rate	500 ms for 8 channels
Rate Accuracy	±0.01% of input frequency
Rate Resolution	±0.4 Hz
Max Input Voltage	±30 V

Installation Guidelines

Ensure the control system is powered down before installing or removing the module from the rack.
Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to sensitive internal components.
Verify that the module is correctly seated in the designated slot and that all field wiring is securely terminated at the FTA.
Maintain proper cable routing practices, keeping signal lines separated from high-voltage power cables to minimize electromagnetic interference (EMI).
Ensure adequate ventilation in the cabinet to maintain operating temperatures within the manufacturer's specified limits.

FAQ

Does this module support redundancy?
No, the MC-TPIX12 module does not support redundancy.

Which IOP modules are compatible with this FTA?
The MC-TPIX12 is designed to be used in conjunction with the MU-PPIX02 or MC-PPIX02 IOP modules.
