Honeywell MU-TAIH53 High Level Analog Input Module 51309138-225

Honeywell MU-TAIH53 High Level Analog Input Module (51309138-225)

Availability: 0 left in stock

DescriptionThe Honeywell MU-TAIH53 (51309138-225) is a high-level analog input module engineered for integration within Honeywell Experion PKS and UCN control...

SKU: MU-TAIH53

Manufacturer: Honeywell
Product No.: MU-TAIH53
Product Type: Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1400g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Honeywell MU-TAIH53 (51309138-225) is a high-level analog input module engineered for integration within Honeywell Experion PKS and UCN control systems. This module serves as a critical interface for field instrumentation, providing 16 differential input channels capable of processing standard industrial voltage and current signals. Designed for reliability in demanding industrial environments, it ensures high-precision data acquisition for pressure, flow, level, and temperature monitoring applications.

Features

16 isolated differential input channels for robust signal acquisition.
Supports standard 0-10 V and 4-20 mA signal ranges.
High measurement accuracy of plus/minus 0.1 percent of full scale.
1500 V electrical isolation between field inputs and system electronics to mitigate ground loops and transients.
Supports redundant module configurations for high-availability process control.
Integrated signal conditioning and A/D conversion for stable performance.
Type S screw terminal assembly for simplified field wiring.

Applications

The MU-TAIH53 is widely utilized in process automation environments, including oil and gas refineries, power generation facilities, and chemical processing plants. It is ideal for interfacing with field transmitters that require high-integrity signal transmission over long distances.

Technical Specifications

Model	MU-TAIH53
Part Number	51309138-225
Input Channels	16 Differential
Input Ranges	0-10 V, 4-20 mA
Accuracy	+/- 0.1 percent of full scale
Isolation	1500 V
Operating Voltage	24 VDC
Power Consumption	1.5 W
Operating Temperature	-20 to 60 deg C
Storage Temperature	-40 to 85 deg C
Terminal Type	Screw Terminals (Type S)

Installation Guidelines

Ensure the control system is powered down before installing or removing the module.
Mount the module in a clean, dry environment within the specified operating temperature range.
Use shielded twisted-pair cabling for field inputs to minimize electromagnetic interference (EMI).
Ensure proper grounding of the module chassis to the system common to maintain isolation integrity.
Verify terminal connections are secure and tightened to prevent intermittent signal loss.
Handle with standard ESD precautions to prevent damage to internal sensitive electronics.

FAQ

What is the primary function of the MU-TAIH53?

The MU-TAIH53 acts as a high-level analog input module for Honeywell Experion PKS and UCN systems, converting field-level analog signals (voltage/current) into digital data for process control.

Does this module support redundancy?

Yes, the MU-TAIH53 is designed to support redundant configurations where two modules operate in parallel to ensure continuous signal acquisition in critical applications.

What type of wiring does this module use?

This module is configured as a Field Termination Assembly (FTA) using Type S screw terminals, which allows for direct connection of field device wiring.
