140DAI55300 (Part Number: 140DAI55300) is a 32-channel AC discrete input module for the Modicon Quantum platform. It interfaces with 115 V AC signals, enabling monitoring of field devices such as limit switches, pushbuttons, and relay contacts.
The module organizes channels into four independent groups of eight, allowing multiple AC phases or sources while maintaining robust isolation and front-panel LED diagnostics for rapid troubleshooting.
| Feature | Specification |
|---|---|
| Input Channels | 32 discrete |
| Voltage Category | 115 V AC |
| Voltage Range | 80–132 V AC |
| Frequency | 47–63 Hz |
| Input Groups | 4 × 8 channels |
| Input Current | 5 mA (average) |
| Input Impedance | 12–15 kΩ |
| Response Time | Off→On: <25 ms On→Off: <30 ms |
| Isolation | Between groups: 1780 Vrms, 60 s Group to bus: 1780 Vrms, 60 s |
| Addressing | 2 input words (32 bits) |
| Diagnostics | 32 green LEDs (input state) 1 red LED (external fault) |
| Bus Current | 300 mA |
| Power Dissipation | 5 W max |
| Weight | 0.45 kg |
Power distribution centers
Water treatment facilities
Heavy manufacturing plants
Large-scale retrofit projects requiring high-density AC inputs
Multiple AC phases supported: each group can use different phases within rated isolation
Terminal Block: 40-pin removable block required (e.g., 140XTS00200)
Red LED: signals loss of field power or configuration mismatch
