BMXDDO6402K Schneider Electric Discrete Output Module

Availability: 94 left in stock

Product Description The BMXDDO6402K is a 64-channel solid-state discrete output module for the Schneider Electric Modicon X80 platform. Using sourcing (positive) logic, it drives DC loads such...

SKU: BMXDDO6402K

Manufacturer: Schneider
Product No.: BMXDDO6402K
Product Type: Discrete Output Module
Product Origin: France
Payment:T/T, Western Union
Weight: 320g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Description

The BMXDDO6402K is a 64-channel solid-state discrete output module for the Schneider Electric Modicon X80 platform. Using sourcing (positive) logic, it drives DC loads such as actuators, solenoids, and indicators. Designed for high-density, high-speed switching, it supports M340 and M580 racks with compact single-slot integration.

Technical Specifications

Item	Specification
Output Channels	64 discrete outputs
Output Type	Solid-state transistor
Logic Type	Positive (sourcing)
Rated Voltage	24 V DC
Voltage Range	19–30 V DC
Current per Channel	0.1 A
Total Module Current	6.4 A max
Response Time	< 1.2 ms (on/off)
Leakage Current	< 0.1 mA (state 0)
Bus Power	160 mA @ 3.3 V DC
Power Dissipation	6.85 W max
Operating Temp	-40°C to 85°C

Typical Applications

Pilot light and indicator arrays
Pneumatic manifold or relay interposing control
High-count discrete outputs in manufacturing automation
Extreme temperature environments such as oil & gas or non-climate-controlled floors

Notes

Overload Protection: Electronic protection per output group prevents hardware damage
Inductive Loads: Suitable for inductive loads; external clamping diodes recommended for high-inductance devices
