Product Description

140AVI03000 (Part Number: 140AVI03000) is an 8-channel differential analog voltage input module for the Modicon Quantum platform. It captures continuous signals from field instruments such as pressure transducers, flow meters, and level sensors.

The module features high galvanic isolation, FM Class 1 Division 2 certification, and a single-slot Quantum format for compact high-density analog integration.


Technical Specifications

Feature Specification
Input Channels 8 differential
Input Type Voltage
Voltage Ranges ±10 V, ±5 V, 1–5 V, 0–10 V, 0–5 V (software configurable)
Resolution 12–16 bit (range-dependent)
Input Impedance > 20 MΩ
Absolute Accuracy 0.05% of full scale @ 25 °C
Isolation Voltage 1780 V AC (channels to bus)
Addressing 9 input words
Bus Current 250 mA
EMC Immunity ESD: 4 kV contact / 8 kV air; EM Field: 10 V/m (IEC 801-2/3)
Operating Temp. 0–60 °C
Net Weight 0.3 kg

Applications

  • Water treatment plants

  • Chemical processing

  • Power generation systems

  • High-speed voltage monitoring and precise sensor feedback


Notes

  • Current signals (4–20 mA): Use 140ACI series or external resistor

  • Terminal block: 40-pin removable (140XTS00200) sold separately

  • Channel configuration: Software-selectable voltage ranges via Unity Pro / Concept
