900A01-0001 Honeywell HC900 Universal Analog Input 16-Bit

Availability: 99 left in stock

Honeywell 900A01-0001 HC900 8-Channel Universal Analog Input Module Product Overview The Honeywell 900A01-0001 is a high-density, high-precision universal analog input module specifically...

SKU: 900A01-0001

Manufacturer: Honeywell
Product No.: 900A01-0001
Product Type: Universal Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Honeywell 900A01-0001 HC900 8-Channel Universal Analog Input Module

Product Overview

The Honeywell 900A01-0001 is a high-density, high-precision universal analog input module specifically engineered for the HC900 Control System. This module provides eight fully independent channels, each capable of interfacing with a diverse array of field sensors including thermocouples, RTDs (Resistance Temperature Detectors), and standard 4–20 mA or voltage transmitters.

By eliminating the need for external signal conditioning, the 900A01-0001 streamlines system architecture. It features integrated 16-bit A/D conversion, internal linearization, and automatic cold-junction compensation (CJC) for temperature sensors. Each channel is galvanically isolated, protecting the HC900 controller logic from field-side transients and electrical noise, making it a reliable choice for critical thermal processing and pharmaceutical manufacturing environments.

Technical Specifications

Comprehensive technical parameters for the 900A01-0001:

Parameter	Specification Details
Model Number	900A01-0001
System Platform	Honeywell HC900 Control System
Number of Channels	8 Universal Inputs (Independently Configurable)
Input Types	Thermocouple (J, K, T, E, R, S, B, N, etc.), RTD (Pt100), mV, V, mA
A/D Resolution	16-bit
Galvanic Isolation	400V AC channel-to-channel / 1500V AC channel-to-logic
Cold Junction Compensation	Internal (±0.5°C accuracy)
Input Impedance	>10MΩ (Voltage/TC inputs), 250Ω (Current inputs)
Power Requirements	24V DC Nominal
Operating Current	25 mA to 40 mA
Operating Temperature	0°C to +60°C
Storage Temperature	-40°C to +85°C
Mounting	Standard HC900 I/O Rack (DIN Rail Compatible)
Weight	0.45 kg (Net) / 1.0 kg (Shipping)
