Allen-Bradley 1756-HSC ControlLogix High Speed Counter Module

Allen-Bradley 1756-HSC ControlLogix High Speed Counter Module

Availability: 7 left in stock

The Allen-Bradley 1756-HSC is a specialized high-speed counter module designed for the ControlLogix platform. This module provides precise pulse counting...

SKU: 1756-HSC

Manufacturer: Allen-Bradley
Product No.: 1756-HSC
Product Type: High Speed Counter Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Allen-Bradley 1756-HSC is a specialized high-speed counter module designed for the ControlLogix platform. This module provides precise pulse counting and frequency measurement capabilities, essential for industrial applications involving high-speed motion control, flow metering, and position tracking. It integrates seamlessly into any standard ControlLogix chassis, allowing for flexible system configuration.

Features

Supports high-speed pulse counting with a range of 0 to 16,214,777.
Equipped with 3 inputs per counter and 4-point outputs for versatile signal integration.
Designed for installation in any available slot within a ControlLogix chassis.
Compatible with 1756-TBCH and 1756-TBS6H removable terminal blocks for efficient wiring.
Optimized for low power consumption with a maximum dissipation of 5.6 Watts at 60 degC.

Technical Specifications

Module Type	High Speed Counter
Inputs	3 per counter
Outputs	4-point
Backplane Current (5V)	300 mA
Backplane Current (24V)	3 mA
Max Power Dissipation	5.6 W at 60 degC
Count Range	0 to 16,214,777

Installation Guidelines

Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-HSC module to prevent electrical damage or backplane faults.
Use appropriate shielded cabling for high-speed pulse signals to minimize EMI interference from surrounding high-voltage equipment.
Verify that the chosen terminal block (1756-TBCH or 1756-TBS6H) is securely seated and that all field wiring is properly terminated.
Maintain proper ventilation in the control cabinet to stay within the module's 60 degC operating limit.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect internal circuitry.

FAQ

What is the primary function of the 1756-HSC?
The 1756-HSC is a high-speed counter module used in Allen-Bradley ControlLogix systems to process fast-pulsed input signals, such as those from encoders or flow sensors, for accurate counting and rate measurement.

Which terminal blocks are compatible with this module?
This module is designed to work with the 1756-TBCH or 1756-TBS6H removable terminal blocks.

Can this module be installed in any slot?
Yes, the 1756-HSC is designed to be installed in any slot within a ControlLogix chassis, provided there is sufficient backplane power available.
