Allen-Bradley 1756-IF4FXOF2F ControlLogix High-Speed Analog I/O Module

Allen-Bradley 1756-IF4FXOF2F ControlLogix High-Speed Analog I/O Module

Availability: 10 left in stock

DescriptionThe Allen-Bradley 1756-IF4FXOF2F is a high-speed, combination analog input/output module designed for the ControlLogix platform. This module features 4 high-speed...

SKU: 1756-IF4FXOF2F

Manufacturer: Allen-Bradley
Product No.: 1756-IF4FXOF2F
Product Type: Analog I/O Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 220g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Allen-Bradley 1756-IF4FXOF2F is a high-speed, combination analog input/output module designed for the ControlLogix platform. This module features 4 high-speed differential analog inputs and 2 high-speed analog outputs, providing precise signal processing for demanding industrial control applications. The unit supports both voltage and current signal ranges, offering flexibility for various sensor and actuator interface requirements.

Features

4 high-speed differential analog inputs with sub-millisecond response times.
2 high-speed analog output channels.
Supports configurable signal ranges including ±10V, 0-10V, 0-5V, and 0-20mA.
High-resolution conversion: 14-bit resolution for voltage and 12-bit for current inputs.
Seamless integration into the ControlLogix backplane for high-speed data exchange.

Technical Specifications

Product Model	1756-IF4FXOF2F
Manufacturer	Allen-Bradley
Module Type	High-Speed Analog I/O
Input Channels	4 Differential
Output Channels	2
Input Ranges	±10V, 0-10V, 0-5V, 0-20mA
Output Ranges	±10V, 0-20mA
Input Resolution	14 bits (voltage), 12 bits (current)
Output Resolution	13 bits (current), 14 bits (voltage)
Weight	0.22 kg

Installation Guidelines

Ensure the ControlLogix chassis is powered down before installing or removing the module.
Verify that the module is fully seated in the chassis slot and secured with the top and bottom mounting screws.
Use shielded twisted-pair cabling for all analog signals to minimize electromagnetic interference (EMI).
Ensure proper grounding of the cable shields at the source or the module end, following standard industrial practices to prevent ground loops.
Keep signal wiring separated from high-voltage power lines and motor drive cabling.

FAQ

What is the primary function of the 1756-IF4FXOF2F?
This module serves as a high-speed interface for analog devices, allowing the ControlLogix controller to read 4 analog inputs and drive 2 analog outputs with high precision and low latency.

Can this module handle both voltage and current signals?
Yes, the module is designed to support both current (0-20mA) and voltage (±10V, 0-10V, 0-5V) signals, which can be configured based on your specific application requirements.
