Configured for high-frequency signal transmission in 3300 XL Proximity Transducer System platforms, the Bently Nevada 330130-040-00-00 (330130 Extension Cable) provides direct physical/electrical execution.

Suffix Breakdown & Model Matrix

  • 330130: 3300 XL Standard Extension Cable Base Model

  • -040: Cable Length Option (4.0 meters / 13.1 feet)

  • -00: Connector Protector and Cable Option (Standard cable)

  • -00: Agency Approval Option (Not required)

Hardware Specifications

Parameter Specification
Model 330130-040-00-00
Brand Bently Nevada
Origin USA
Weight 0.250 kg estimate
Dimensions 4.0 meters (13.1 feet) electrical/physical length
Operating Temp -51 deg C to +177 deg C nominal
Power Consumption Passive coaxial component (0 mA active load)
Characteristic Impedance 75 ohm nominal
Connector Type Miniature coaxial ClickLoc connectors

Mechanical Monitoring & TSI Technical Attributes

The 330130 extension coaxial assembly is manufactured to maintain balanced electrical metrics necessary for precise eddy-current probe scaling across the transducer circuit loop. Field calibration routines rely on strict total system electrical length tuning to complete proper gap voltage validation targeting a -10 VDC baseline setting. This 4.0 meter line provides constant characteristic impedance match parameters to support effective cross-talk suppression. This layout prevents high-frequency data corruption from outside electromagnetic fields while routing the low-amplitude high-frequency signals driven by complex rotor dynamics directly to the Proximitor loop processing electronics.

Frequently Asked Questions

  • Q: What happens to the proximity loop calibration if this 4.0 meter cable is shorted or physically altered?

    • A: Any modifications to the physical length alter the matched electrical length, shifting the eddy-current probe scaling parameters and inducing critical measurement errors at the monitor.

  • Q: Does this standard cable model feature specialized external armor or connector protectors?

    • A: No. The -00 suffix option denotes a standard unarmored cable configuration without built-in connector protectors. It requires external conduit routing in harsh environments.

  • Q: How do the integrated miniature ClickLoc coaxial connections resist unintended detachment under heavy machine vibration?

    • A: ClickLoc connectors utilize a positive mechanical locking detent mechanism that guarantees constant contact compression and cross-talk suppression during continuous physical vibration.

Field Installation Guidelines

  1. Terminate all power to the target monitoring loops and establish zero-energy conditions. Verify the intermediate junction enclosures are completely free of oil, moisture, or dirt contamination.

  2. Carefully pull the 330130 coaxial line through the designated protecting tray paths, preventing any sharp bends or pinching actions that degrade the internal insulation layers.

  3. Align and push the miniature ClickLoc coaxial interface onto the proximity probe connector till a distinct mechanical locking engage point is achieved.

  4. Execute physical gap voltage validation on the driver terminal blocks to ensure the sensor output settles at the targeted -10 VDC baseline position.

  5. Seal the raw ClickLoc coaxial junction using self-fusing silicone electrical insulation tape to provide defense against corrosive industrial fluids, grounding loop risks, and casing contact shorts.
