The Bently Nevada 3300/47 Differential Expansion Monitor is a specialized rack-mounted module engineered to track the axial thermal growth between a turbine rotor and its casing. By monitoring these critical clearance changes, the unit helps prevent mechanical contact and potential catastrophic equipment failure during machine startup, operation, or shutdown cycles.
Features
- Continuous monitoring of differential expansion parameters for large rotating machinery.
- Integration with proximity probes and Proximitor sensors for high-precision measurement.
- Dual relay outputs configured for Alert and Danger alarm logic.
- Integrated LED status indicators for visual confirmation of OK, Bypass, Alert, and Danger states.
- Signal conditioning designed for high accuracy in demanding industrial environments.
Applications
This monitor is primarily deployed in power generation and heavy industrial facilities to protect steam turbines and other large rotating assets where thermal expansion management is essential for operational integrity.
Technical Specifications
| Model | 3300/47-XX-03-01-00 |
| Operating Temperature | 0 to 60 degC |
| Power Consumption | 1.5 W (typical) |
| Sensitivity | 200 mV/mil (8 V/mm) or 100 mV/mil (4 V/mm) |
| Signal Accuracy | +/- 0.33% typical, +/- 1% max at 25 degC |
| Output Signals | 4 to 20 mA, 1 to 5 VDC, 0 to -10 VDC |
Installation Guidelines
- Ensure the 3300 series rack is properly grounded to a clean instrument earth to minimize noise interference.
- Power down the rack before inserting or removing the module to prevent electrical damage.
- Verify that the probe configuration matches the specific requirements of the XX measurement range and Proximitor sensor interface.
- Route signal cables away from high-voltage power lines and sources of electromagnetic interference (EMI).
- Maintain adequate ventilation within the cabinet to ensure the ambient temperature remains within the 0 to 60 degC range.
FAQ
What is the primary function of the 3300/47 module? It measures the differential thermal expansion between the turbine rotor and casing to prevent mechanical interference.
Does this module include relay outputs? Yes, this specific model (03-01-00) includes dual relay outputs configured for Alert and Danger alarm conditions.
What input type does it support? It is designed to accept inputs from proximity probes via standard Proximitor sensors.
