GE IS200EPDMG1B Power Distribution Board

GE Fanuc IS200EPDMG1B Exciter Power Distribution Board

التوفر: 1 متوفر في المخزون

The IS200EPDMG1B is an essential Power Distribution Module engineered for the GE EX2100 Excitation Control system. This board acts as...

رمز المنتج: IS200EPDMG1B

Manufacturer: GE FANUC
Product No.: IS200EPDMG1B
Product Type: Power Distribution Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1150g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

The IS200EPDMG1B is an essential Power Distribution Module engineered for the GE EX2100 Excitation Control system. This board acts as the centralized power management hub, responsible for routing and regulating voltage to various control, I/O, and protection modules within the exciter cabinet. By providing a stable, filtered power supply, the module plays a critical role in ensuring the operational integrity and reliability of large-scale generator excitation systems.

System Functionality

Designed for installation on the Exciter Power Backplane (EPBP), the IS200EPDMG1B streamlines internal power distribution and simplifies maintenance workflows. The module is engineered to minimize downtime by providing clear diagnostic access and efficient cable routing. It effectively isolates sensitive control electronics from power fluctuations, protecting the broader control architecture from instability.

Power Architecture

The module supports a robust, redundant power input configuration. It accepts dual 120 VAC inputs, which are rectified via external DACA converters, and an auxiliary 125 VDC station battery feed. These inputs are combined through external diodes to generate the P125V and R125V DC rails. The system features a center-grounded design, establishing a balanced +62.5 VDC and -62.5 VDC environment, which significantly reduces common-mode noise and enhances signal integrity for the excitation control system.

Features

Redundant power input support (Dual 120 VAC and 125 VDC battery).
Center-grounded output architecture (+/- 62.5 VDC) for balanced power delivery.
Integrated filtering to mitigate electrical noise and transient interference.
Optimized for direct integration with EX2100 Exciter Power Backplane (EPBP) systems.
Simplified terminal interface via TB1 for reliable power connections.

Installation Guidelines

Ensure the cabinet power is fully isolated before installing or removing the module from the EPBP.
Verify that all AC and DC input wiring is properly secured to the TB1 terminal block according to system schematics.
Maintain proper grounding practices to preserve the center-grounded reference.
Ensure the module is operated within the specified ambient temperature range of 0 to 60 deg C.
Keep the installation environment free of excessive dust and moisture to maintain the non-condensing humidity requirements.

Technical Specifications

Model	IS200EPDMG1B
Series	EX2100 Excitation Control
Input Voltage	Dual 120 VAC / 125 VDC (Battery)
Output Voltage	+62.5 VDC / -62.5 VDC (Center Grounded)
Interface	TB1 Terminal Block
Operating Temperature	0 to 60 deg C
Humidity	5 to 95 percent (non-condensing)

FAQ

What is the primary purpose of the IS200EPDMG1B?
It serves as the power distribution hub for the EX2100 exciter, routing rectified AC and battery DC power to control and protection modules while maintaining a stable, center-grounded voltage.

Is the IS200EPDMG1B compatible with other EX2100 modules?
Yes, it is designed specifically for the EX2100 series and mounts directly onto the Exciter Power Backplane (EPBP).

How is the power balanced in this module?
The module utilizes a center-grounded architecture that provides a symmetrical +62.5 VDC and -62.5 VDC output, which helps isolate the control electronics from ground-related noise.
