Emerson Ovation 1C31116G03 Series Datasheet & Technical Manual

التوفر: 99 متوفر في المخزون

Emerson 1C31116G03 Ovation Series The Emerson 1C31116G03, also cataloged as the 1C31116G03 Digital Output Module, operates as a dedicated hardware...

رمز المنتج: 1C31116G03

Manufacturer: Emerson
Product No.: 1C31116G03
Product Type: Digital I/O Cards
Product Origin: USA
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

Emerson 1C31116G03 Ovation Series

The Emerson 1C31116G03, also cataloged as the 1C31116G03 Digital Output Module, operates as a dedicated hardware component for converting digital commands from Ovation controllers into discrete output signals within Ovation DCS networks.

Hardware Specifications

Parameter	Specification
Model	1C31116G03
Brand	Emerson
Origin	Thailand
Weight	0.2 kg
Dimensions	2.5 x 9.7 x 12.2 cm
Operating Temp	-20 to +70 deg C
Power Consumption	24 VDC nominal (rack powered)
Output Channels	32 digital output channels
Signal Voltage Range	24 VDC or 48 VDC (jumper selectable)
Output Type	Isolated, single-ended
Load Capacity	Up to 0.5 A per channel
Response Time	<5 ms typical
Isolation	2500 VDC channel-to-backplane isolation
Diagnostics	Built-in fault detection, LED indicators per channel
Protection	Short-circuit and overload protection
Storage Temp	-40 to +85 deg C
Humidity Tolerance	5-95% RH, non-condensing
Certifications	UL, CSA, IEC 61131-2 compliant

Process Control and DCS Instrumentation

The electrical topology incorporates channel-to-channel isolation networks designed to suppress high-voltage common-mode transients from disrupting the inner processing layer. Dedicated circuit paths route output current loops through individual semiconductor switches, regulating inductive and resistive field loads up to 0.5 A per node. Integral diagnostic arrays track operational status indicators across the interface terminal plane, maintaining constant open-circuit and thermal overload fault evaluation during high-frequency execution cycles.

Frequently Asked Questions

Q: How is the physical signal voltage layer configured for 24 VDC or 48 VDC operational baselines?

A: Selection between the 24 VDC and 48 VDC field output voltage thresholds requires manual position adjustments of the structural jumpers located directly on the module circuit board prior to rack mounting.

Q: What mitigation actions does the hardware execute during an external dead short-circuit event?

A: Onboard protection circuitry isolates the affected path via electronic current-limiting boundaries, resetting automatically once the field wiring short-circuit condition is rectified.

Field Installation Guidelines

Lock the module alignment rails within the designated Ovation chassis slot, engaging the low-impedance multi-pin backplane connector to complete the internal power circuit. Separate all field discrete output cabling runs from parallel high-voltage AC distribution bus ducts inside the cable trays to prevent inductive interference. Connect all control circuit common shield wires to the plant master instrumentation earth bus at a single connection node. Maintain unobstructed space clearances above and below the rack perimeter to ensure steady vertical air flow currents for continuous thermal dissipation.
