IS420ESWBH1AE GE Ethernet IONet Switch

GE IS420ESWBH1AE Mark VIe IONet Switch

التوفر: 10 متوفر في المخزون

The GE IS420ESWBH1AE, also cataloged as the IS420ESWB Ethernet IONet Switch, operates as a dedicated hardware component for deterministic industrial...

رمز المنتج: IS420ESWBH1AE

Manufacturer: GE Fanuc
Product No.: IS420ESWBH1AE
Product Type: Ethernet Switches
Product Origin: USA
Payment:T/T, Western Union
Weight: 1100g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

The GE IS420ESWBH1AE, also cataloged as the IS420ESWB Ethernet IONet Switch, operates as a dedicated hardware component for deterministic industrial communication and real-time control network switching within GE Mark VIe and Mark VIeS platforms. The switch bridges sixteen 100Base-TX copper RJ45 channels with one 100Base-FX multi-mode fiber-optic port via LC connectors to route unmanaged time-critical telemetry across control racks.

Hardware Specifications

Parameter	Specification
Model	IS420ESWBH1AE (IS420ESWB)
Brand	GE (General Electric)
Origin	USA
Dimensions	7.40 x 3.40 x 2.20 in (18.79 x 8.64 x 5.59 cm)
Operating Temp	-40 to 70 deg C (-40 to 158 deg F)
Power Consumption	Powered via 24 / 28 VDC Dual Inputs
Output Voltage	24 / 28 VDC Internal Supply Bus
Copper Ports	16 x 100Base-TX RJ45 Interfaces
Fiber Ports	1 x 100Base-FX Multi-Mode Fiber (LC Connector)
Functional Abbreviation	ESWB
System Compatibility	GE Mark VIe and Mark VIeS Integrated Control Systems

Backplane Bus Communication Velocity and Network Density Scaling

The IS420ESWBH1AE manages local backplane bus communication velocity across distributed control node topologies, using high-density port arrays to maintain deterministic Ethernet data frame transport. Through hardware-level firmware flash compatibility, the unit provides zero-configuration boot sequences while preventing packet collisions across high-density I/O clusters. The dedicated 100Base-FX LC multi-mode fiber interface isolates noise-sensitive long-distance cabinet links from local copper loop transients.

Frequently Asked Questions

Q: What power input voltage range does the IS420ESWBH1AE switch accept?

A: The switch operates on nominal 24 / 28 VDC redundant power supply connections to maintain uninterrupted network fabric availability.

Q: What type of fiber-optic cabling is required for the single optic port on this model?

A: The onboard fiber port requires 100Base-FX multi-mode fiber terminated with a standard duplex LC-type connector.

Q: Can the IS420ESWBH1AE be mounted directly on a standard DIN-rail inside an enclosure?

A: Yes, the unit is constructed with a vertical DIN-rail mounting chassis designed for direct mechanical snap-on installation within industrial control cabinets.

Field Installation Guidelines

Mount the switch vertically onto a grounded 35 mm DIN-rail inside the control enclosure, ensuring top and bottom ventilation clearances of at least 50 mm.
Connect primary and secondary 24 / 28 VDC power feeds to the removable terminal block, observing proper terminal polarity.
Attach chassis earth ground directly to the dedicated earthing stud using a short, low-impedance copper wire strap.
Plug field Ethernet cables into the 100Base-TX RJ45 copper ports (1 through 16) until retaining clips snap into position.
Clean the fiber optical interface end-face before inserting the LC multi-mode connector into the 100Base-FX fiber socket.
