GE DS3800NMEC1K1K Mark IV Motor Exciter Control Board

GE Fanuc DS3800NMEC1K1K Mark IV Motor Exciter Control Board

التوفر: 0 متوفر في المخزون

DescriptionThe DS3800NMEC1K1K is a specialized motor exciter control board engineered for the GE Speedtronic Mark IV turbine control system. This...

رمز المنتج: DS3800NMEC1K1K

Manufacturer: GE FANUC
Product No.: DS3800NMEC1K1K
Product Type: Motor Exciter Control Board
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

Description

The DS3800NMEC1K1K is a specialized motor exciter control board engineered for the GE Speedtronic Mark IV turbine control system. This component serves as a critical interface for managing excitation parameters in steam and gas turbine applications, ensuring precise regulation of turbine rotation and energy conversion processes. Built for high-reliability utility and industrial environments, the module facilitates stable power harvesting and grid synchronization through advanced signal processing and frequency management.

Features

Field Tuning: Equipped with an onboard variable resistor featuring a calibrated 0-100 scale, allowing for manual adjustment of excitation parameters.
Signal Processing: Incorporates ten semi-circular transistors dedicated to signal amplification and modulation tasks.
Timing Precision: Features a high-stability crystal oscillator to maintain accurate clock pulses for system logic.
Robust Architecture: Utilizes a dense circuit layout containing 35 integrated circuits, including EPROM and EEPROM units for firmware and logic storage.
Noise Suppression: Integrated network of resistors, capacitors, and diodes designed to filter electrical interference and manage energy distribution.
Connectivity: Standardized 6-point male pin interface for secure mating with the Mark IV backplane.

Installation Guidelines

ESD Precautions: Always handle the board using proper electrostatic discharge (ESD) protection, including wrist straps and grounded work surfaces, to prevent damage to sensitive ICs.
Power Status: Ensure the turbine control system is fully de-energized before inserting or removing the module from the rack.
Seating: Verify that the 6-point male connector is properly aligned and fully seated within the backplane slot to ensure reliable electrical contact.
Calibration: After installation, verify the variable resistor setting against system documentation to ensure excitation levels meet site-specific requirements.
Environment: Maintain ambient operating temperatures between 0 deg C and 60 deg C to ensure component longevity.

Technical Specifications

Model	DS3800NMEC1K1K
System	Speedtronic Mark IV
Module Type	Motor Exciter Control Board
Integrated Circuits	35 (EPROM/EEPROM)
Adjustment	Variable Resistor (0-100)
Connector Type	6-Point Male
Operating Temp	0 to 60 deg C
Storage Temp	-40 to 85 deg C

FAQ

Q: Is this board compatible with other Speedtronic systems?
A: The DS3800NMEC1K1K is specifically designed for the Mark IV series. It is not intended for use in earlier or later Speedtronic generations.

Q: What is the purpose of the black knob on the board?
A: The black knob controls the onboard variable resistor, which allows field technicians to manually fine-tune the excitation parameters for the motor.

Q: Does this module require specific environmental conditions?
A: Yes, it is rated for operation in temperatures between 0 and 60 deg C. Ensure the control cabinet provides adequate ventilation to avoid overheating.
