P0916PW Foxboro Analog Input Module

Foxboro P0916PW FBM | Analog Input Modules

Foxboro P0916PW FBM | Analog Input Modules

Disponibilidad: 10 Quedan en stock

Foxboro P0916PW Analog Input Modules The Foxboro P0916PW, also cataloged as the FBM Analog Input Modules, operates as a dedicated...

Código: P0916PW

Manufacturer: Foxboro
Product No.: P0916PW
Product Type: Analog Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 460g
Shipping port: Xiamen
Warranty: 12 months

Descripción Reseñas

Foxboro P0916PW Analog Input Modules

The Foxboro P0916PW, also cataloged as the FBM Analog Input Modules, operates as a dedicated hardware component for converting continuous field process signals into digital telemetry within Foxboro I/A Series DCS networks. The module interfaces 16 isolated analog input channels supporting standard 4-20 mA DC transmitter inputs. Utilizing 12-bit to 16-bit A/D conversion stages, the unit routes digitized process variables across the carrier backplane while maintaining galvanic isolation between field instrument loops and central logic processing units.

Hardware Specifications

Parameter	Specification
Model	P0916PW
Brand	Foxboro
Origin	USA
Weight	0.46 kg (1.01 lbs)
Dimensions	Standard FBM form factor module
Operating Temp	0 deg C to +60 deg C
Power Consumption	8 W approx
Product Type	Analog Input Modules
Input Channels	16 isolated analog input channels
Signal Range	4-20 mA DC process signals
Resolution	12-bit to 16-bit A/D conversion
Galvanic Isolation	Channel-to-channel and channel-to-system isolation
System Interface	Foxboro I/A Series redundant communication bus
Power Supply Input	24 VDC nominal
Storage Temp	-40 deg C to +85 deg C
Operating Humidity	5% to 95% non-condensing

Process Control & Field Instrument Architecture

Engineers configure the analog input module to process continuous current signals from flow, level, pressure, and temperature transmitters. Integration with 4-20 mA HART loop protocol instruments allows secondary variable telemetry and field diagnostics to pass across the input channels without degrading primary signal digitization rates. Internal channel-to-channel isolation barriers eliminate ground loop currents caused by potential differences between field grounding points and the control cabinet backplane. Onboard diagnostics continuously monitor channel integrity, driving fault LEDs and flagging circuit anomalies back to the control processor.

Frequently Asked Questions

Q: How does channel-to-channel isolation protect the module during field ground fault conditions?

A: Individual galvanic isolation barriers prevent fault voltages or stray ground currents on one transmitter loop from propagating to adjacent channels or damaging central system microprocessors.

Q: Can an operator replace a faulty module while the system backplane remains powered?

A: Yes, the unit supports hot-swapping on an energized backplane carrier, allowing field technicians to replace the module without shutting down system power or interrupting adjacent I/O modules.

Field Installation Guidelines

Backplane Alignment: Slide the module into the designated baseplate slot along card guides until the rear connector fully mates with the backplane receptacle.
Shield Line Earthing: Terminate 4-20 mA signal cable shields at a dedicated grounding bar inside the panel enclosure to prevent high-frequency noise interference.
Conduit Wiring Separation: Route low-voltage analog input cabling in separate cable trays away from high-voltage AC power feeds and motor drive circuits.
Supply Line Protection: Connect the cabinet baseplate to dual 24 VDC power supplies to maintain continuous operation during primary power source interruptions.
Enclosure Environmental Control: Verify cabinet ventilation and cooling fans keep the ambient operating temperature between 0 deg C and +60 deg C.
