Bently Nevada 3500/77M 140734-07 Pressure Monitor Module

Bently Nevada 3500/77M 140734-07 Cylinder Pressure Monitor Module

Availability: 10 left in stock

DescriptionThe Bently Nevada 3500/77M 140734-07 is a high-performance four-channel monitor module engineered for the 3500 Machinery Protection System. This module...

SKU: 140734-07

Manufacturer: Bently Nevada
Product No.: 140734-07
Product Type: Pressure Monitor Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 800g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Bently Nevada 3500/77M 140734-07 is a high-performance four-channel monitor module engineered for the 3500 Machinery Protection System. This module is specifically designed to measure and analyze dynamic cylinder pressure in reciprocating machinery, such as compressors and reciprocating engines. By processing signals from dynamic pressure transducers, the 3500/77M provides continuous monitoring of pressure profiles, peak values, and critical diagnostic parameters to ensure machinery integrity and prevent catastrophic failure.

Features

Four independent monitoring channels for high-density data acquisition.
Compatible with dynamic cylinder pressure transducers.
Provides real-time cylinder pressure waveform analysis, peak pressure tracking, and diagnostic parameter calculation.
Programmable alert and danger thresholds with configurable voting logic for alarm and trip functions.
Seamless integration into the 3500 rack system, fully configurable via Bently Nevada 3500 Rack Configuration Software.

Applications

Reciprocating compressors.
Large-scale reciprocating engines.
Machinery protection systems requiring cylinder pressure monitoring and diagnostic waveform capture.

Technical Specifications

Product Model	3500/77M
Order Code	140734-07
Channels	4
Operating Temperature	-30 degC to +65 degC
Storage Temperature	-40 degC to +85 degC
Humidity	95% non-condensing
Power Consumption	Supplied via 3500 rack backplane

Installation Guidelines

Ensure the 3500 rack is powered down before inserting or removing the module to prevent electrical damage.
Use appropriate ESD protection when handling the module to avoid damage to sensitive electronic components.
Ensure the module is fully seated in the rack slot and the front panel screws are tightened to maintain proper grounding and EMI shielding.
Route signal cables away from high-voltage lines or sources of electromagnetic interference to maintain signal integrity.
Verify that the I/O module and the monitor module match the configuration defined in the 3500 software.

Compliance and Certifications

Safety Standards: EN 61010-1, LV Directive 2014/35/EU
EMC Compliance: EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions)
Hazardous Area: CSA/NRTL/C Class I, Zone 2
RoHS: Directive 2011/65/EU compliant

FAQ

Does this module include the I/O card?

The 3500/77M module typically requires a corresponding I/O module for field wiring termination. Please verify if your specific order includes the required I/O module or if it is being purchased separately.

Is this module compatible with all 3500 racks?

The 3500/77M is designed for standard 3500 rack systems. Ensure your rack firmware and configuration software versions are compatible with this module revision.
