330901-00-90-05-02-00 Bently Nevada Proximity Sensors

330901-00-90-05-02-00 Bently Nevada 3300 NSv Proximity Probes

330901-00-90-05-02-00 Bently Nevada 3300 NSv Proximity Probes

Availability: 10 left in stock

The Bently Nevada 330901-00-90-05-02-00, also cataloged as the 330901 Proximity Sensors, operates as a dedicated hardware component for non-contact shaft...

SKU: 330901-00-90-05-02-00

Manufacturer: Bently Nevada
Product No.: 330901-00-90-05-02-00
Product Type: Proximity Sensors
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Bently Nevada 330901-00-90-05-02-00, also cataloged as the 330901 Proximity Sensors, operates as a dedicated hardware component for non-contact shaft vibration and position measurement within 3300 NSv Machinery Monitoring System platforms. The assembly features a 1/4-28 UNF thread profile with a 0.0 in unthreaded length, a 9.0 in overall case length, and a 0.5 m (20 in) FEP-insulated coaxial cable terminated with a miniature coaxial ClickLoc connector.

Hardware Specifications

Parameter	Specification
Model	330901-00-90-05-02-00
Brand	Bently Nevada
Origin	United States
Weight	0.5 kg (Shipping Weight: 2.5 kg)
Dimensions	Standard 1/4-28 UNF case (9.0 in case length)
Operating Temp	-51 deg C to +177 deg C (-60 deg F to +350 deg F)
Power Consumption	Passive transducer (Powered via Proximitor Sensor)
Case Material	AISI 304 Stainless Steel (SST)
Tip Material	Polyphenylene Sulfide (PPS)
Cable Type	75 Ohm coaxial, FEP insulated, standard cable
Total Length Option	0.5 m (20 in)
Unthreaded Length	0.0 in
Overall Case Length	9.0 in
Connector Option	Miniature coaxial ClickLoc connector
Agency Approval	Not required (00 Option)

Mechanical Monitoring & TSI Performance

The 330901-00-90-05-02-00 probe is designed for tight-clearance rotor dynamics monitoring, where physical spatial limits restrict standard 5 mm or 8 mm probe installations. In conjunction with a matching 3300 NSv Proximitor Sensor, the eddy-current probe scaling delivers a calibrated linear output proportional to the gap distance between the PPS probe tip and the target shaft surface. Achieving proper gap voltage validation (typically targeted at -10 VDC during physical installation calibration) ensures optimum dynamic linear range and effective cross-talk suppression between closely spaced transducer channels in counter-bored machinery locations.

Frequently Asked Questions

Q: What is the correct target gap voltage when setting up the 330901-00-90-05-02-00 probe?

A: Physical mounting position should be adjusted mechanically until the Proximitor Sensor output reads approximately -10 VDC, corresponding to the midpoint of the probe linear range.

Q: Can the 0.5 m probe cable be connected directly to a 3300 NSv monitor channel?

A: No. The 0.5 m probe length requires a matching 3300 NSv extension cable to achieve the required 5 m or 7 m total system length specified for the paired Proximitor Sensor.

Q: What material constitutes the probe tip and case assembly?

A: The probe body is constructed from AISI 304 stainless steel, and the probe tip is molded from polyphenylene sulfide (PPS) high-temperature polymer.

Field Installation Guidelines

Mount the probe into the threaded machine port using standard hand tools; avoid over-torquing to prevent casing shear or thread binding.
Maintain minimum 5-thread engagement (NPT/UNF standard practice) when installing probe fittings into machine housings.
Validate mechanical center alignment to maintain radial clearance and prevent shaft contact during thermal expansion cycles.
Clean and inspect the ClickLoc miniature coaxial connector before mating, ensuring lock engagement prevents oil intrusion and signal contamination.
