Bently Nevada 140072-04 3500/45 Position Monitor Module

Availability: 10 left in stock

The Bently Nevada 140072-04 is a 3500/45 Position Monitor module engineered for the continuous surveillance of axial displacement and shaft...

SKU: 140072‑04

Manufacturer: Bently Nevada
Product No.: 140072‑04
Product Type: Position Monitor Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 800g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Bently Nevada 140072-04 is a 3500/45 Position Monitor module engineered for the continuous surveillance of axial displacement and shaft position in critical rotating machinery. As a core component of the 3500 rack-based system, this module processes inputs from proximity probes and Proximitor sensors to deliver real-time data, ensuring that machinery stays within safe operational parameters. It is widely utilized to trigger protective trips or alerts, preventing mechanical failure due to excessive axial movement.

Features

Four independent monitoring channels for comprehensive shaft analysis.
Direct compatibility with industry-standard proximity probe and Proximitor sensor systems.
Configurable alert and danger setpoints for precise machinery protection.
Full integration with the 3500 rack system, allowing for seamless communication with relay and communication modules.
Continuous self-diagnostics to ensure system integrity and measurement accuracy.

Applications

Steam and gas turbines.
Centrifugal compressors and blowers.
Large pumps and motors.
Critical rotating assets requiring axial position monitoring.

Technical Specifications

Manufacturer	Bently Nevada
Model / Part Number	140072-04
Module Type	3500/45 Position Monitor
Power Consumption	7 W (typical)
Operating Temperature	-30 degC to +65 degC
Storage Temperature	-40 degC to +85 degC
Relative Humidity	95%, non-condensing

Installation Guidelines

Ensure the 3500 rack is powered down before inserting or removing the module.
Use appropriate ESD protection when handling the module to prevent damage to sensitive internal components.
Verify that the module is fully seated in the rack slot and that the front panel screws are tightened to ensure proper grounding.
Route signal cables away from high-voltage lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
Ensure all field wiring is terminated according to the specific 3500 system configuration documentation.

Compliance and Certifications

Safety Standards: EN 61010-1, LV Directive 2014/35/EU
EMC Compliance: EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions)
Hazardous Area: CSA/NRTL/C Class I, Zone 2; ATEX options available
Environmental: RoHS Directive 2011/65/EU compliant

FAQ

Does this module support relay logic?

Yes, the 3500/45 module integrates with the 3500 rack system, allowing users to configure alarm and trip logic that can trigger relay outputs for machinery shutdown.

What type of sensors does the 140072-04 support?

This module is designed to interface with Bently Nevada proximity probes and Proximitor sensors to measure axial position and displacement.
