Bently Nevada TK15 80917-01 Keyphasor Conditioner and Power Supply

3500 Series Communication Card | Buy Bently Nevada 136188-02

3500 Series Communication Card | Buy Bently Nevada 136188-02

Availability: 10 left in stock

Product Overview The Bently Nevada 3500/92 (Part Number 136188-02) acts as the high-speed data interface between the 3500 Machinery Protection System and external industrial...

SKU: 3500/92 136188-02

Manufacturer: Bently Nevada
Product No.: 3500/92 136188-02
Product Type: Ethernet I/O Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Bently Nevada 3500/92 (Part Number 136188-02) acts as the high-speed data interface between the 3500 Machinery Protection System and external industrial networks. This Communication Gateway module aggregates critical machinery data—including vibration levels, axial position, speed, and temperature—directly from the 3500 rack backplane. It translates this proprietary internal data into standard Modbus RTU (RS-485) and Ethernet protocols, enabling seamless integration with Distributed Control Systems (DCS), PLCs, and SCADA platforms. We provide this unit as 100% Brand New and Original in Factory Packing, ensuring your plant's condition monitoring remains uninterrupted and accurate.

Technical Specifications

Attribute	Specification Value
Model Number	3500/92
Part Number	136188-02
I/O Module Type	Ethernet / RS485 Modbus
Protocol Support	Modbus RTU (Serial) and Modbus/TCP (Ethernet)
Communication Ports	Dual Serial (RS-485) and Ethernet Port
Baud Rate	Configurable up to 19.2 kbps (Serial)
Isolation	500 Vdc Galvanic Isolation
Operating Temp	0°C to +60°C (32°F to +140°F)
Dimensions	24.3 cm x 2.4 cm x 24.1 cm
Shipping Weight	0.45 kg
Certifications	CE, UL, CSA, SIL3 System Compliant

Engineering Advantages

Multifaceted Connectivity: The 136188-02 combines both RS-485 serial and Ethernet capabilities in a single I/O module. This allows the 3500 rack to communicate with legacy serial masters and modern Ethernet-based DCS networks simultaneously.
High-Volume Data Mapping: The module manages extensive register maps, transmitting hundreds of static and status variables. This provides external systems with a granular view of machinery health without the need for complex, manual hard-wiring of analog outputs.
System Integrity Protection: Galvanic isolation shields the internal 3500 rack electronics from external electrical noise and ground loops common in industrial communication cables. This ensures that a fault on the Modbus network never compromises the primary protective trip functions of the monitoring rack.
Deterministic Communication: The gateway utilizes a high-speed system bus to pull data from individual monitor modules. This deterministic approach ensures that alarm updates and status changes reach the operator's console with minimal latency, supporting rapid response to abnormal machinery conditions.
Modular Hot-Swap Capability: Like all 3500 series modules, the 136188-02 supports replacement while the rack remains powered. Maintenance teams can swap communication gateways without halting machinery protection, ensuring 24/7 asset availability.

FAQs

Does the 136188-02 require specialized software for configuration?

Yes. You configure the Modbus register maps and communication parameters using the Bently Nevada 3500 Rack Configuration Software. This allows you to tailor the data output to match your specific DCS or SCADA register requirements.
Can this module transmit dynamic waveforms for vibration analysis?

The 3500/92 is primarily designed for static data and status information (e.g., overall vibration levels, gap voltages, and alarm states). For high-resolution dynamic waveform analysis, you typically require the 3500/22M Transient Data Interface (TDI) and System 1 software.
Is this part number compatible with both full-size and mini-racks?

The 136188-02 integrates seamlessly with both the 3500/05 Full-Size Rack and the 3500/05 Mini-Rack. It occupies one full-height slot in the chassis.
What is the condition of this specific unit?

We guarantee this is a 100% Brand New and Original 136188-02 module. Although the manufacturer may have officially discontinued the series, we provide authentic, factory-sealed stock to ensure your legacy systems remain fully supported with genuine hardware.
