80026-529-01 Rockwell Automation PowerFlex 7000 Spare

Availability: 20 left in stock

Product Overview The Allen-Bradley 80026-529-01 functions as a high-precision switching power supply specifically engineered for the PowerFlex 7000 Medium Voltage (MV) AC...

SKU: 80026-529-01

Manufacturer: Allen Bradley
Product No.: 80026-529-01
Product Type: PowerFlex 7000 Series
Product Origin: USA
Payment:T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Allen-Bradley 80026-529-01 functions as a high-precision switching power supply specifically engineered for the PowerFlex 7000 Medium Voltage (MV) AC drive system. This module converts single-phase AC input into stable DC power to support the drive’s control circuitry and critical gate-driving functions. It maintains consistent voltage regulation even under the fluctuating load conditions typical of heavy industrial environments. We supply this unit as 100% Brand New and Original, ensuring your PowerFlex 7000 system operates with factory-certified efficiency and maximum uptime.

Technical Specifications

The 80026-529-01 utilizes a high-frequency switching architecture to deliver 1kW of power within a compact industrial footprint.

Attribute	Specification Details
Catalog Number	80026-529-01
Compatible Series	PowerFlex 7000 Medium Voltage Drives
Input Voltage	100-240 VAC, Single-Phase
Input Frequency	50/60 Hz
Output Power	1000 W (1 kW)
Efficiency	High-efficiency switching design
Operating Temperature	0 to 50 degrees Celsius
Humidity	5% to 95% Non-condensing
Protection	Overvoltage and Short-Circuit Protection
Mounting Architecture	Internal Panel / Enclosure Mount
Weight	1.5 to 2.0 kg
Country of Origin	USA

Engineering Advantages

Optimized for MV Drive Harmonics: Medium voltage drive cabinets often present challenging electromagnetic environments. The 80026-529-01 features integrated filtering to suppress internal noise and resist external interference, preventing logic errors in the PowerFlex 7000 control boards.
Thermal Resilience for Continuous Duty: The power supply architecture manages heat dissipation efficiently, supporting continuous 24/7 operation in process control, power generation, and wastewater treatment facilities without thermal derating up to 50 degrees Celsius.
Comprehensive Fault Protection: Built-in overvoltage and short-circuit safeguards immediately isolate the power supply in the event of a downstream fault. This protection prevents localized electrical issues from damaging the expensive control hardware within the PowerFlex 7000 lineup.
Seamless Form-Factor Integration: Designed exclusively for the PowerFlex 7000, this module utilizes standard mounting points and connector orientations found in MV drive enclosures. This eliminates the need for custom brackets or wiring modifications during hardware replacement.

FAQs

Q: Can I use the 80026-529-01 with PowerFlex 750 or 755 series drives?

A: No. This power supply is engineered specifically for the PowerFlex 7000 Medium Voltage AC Drives. The internal voltage requirements and connector pinouts differ significantly from the low-voltage PowerFlex 750-series architecture.

Q: Does this module require external cooling fans?

A: The 80026-529-01 relies on the airflow managed by the PowerFlex 7000 drive's main cooling system. Ensure that the drive’s intake filters are clean and the internal cabinet fans function correctly to maintain the power supply's operating temperature within the 0 to 50 degrees Celsius range.

Q: What is the difference between the 80026-529-01 and the 80026-518-01-R?

A: The 80026-529-01 is a 1000W primary switching supply for specific PowerFlex 7000 configurations. The 80026-518-01-R is a multi-output DC switching supply (typically 5/15/24 VDC) used in different sub-systems. Always verify the part number on your existing unit’s nameplate before ordering to ensure electrical compatibility.

Q: Is any software configuration needed after installation?

A: No. The 80026-529-01 is a hardware-level power component. Once mounted and wired according to the PowerFlex 7000 manual, it provides immediate DC power to the connected control boards upon system startup.
