Allen-Bradley 1746-OV32 SLC 500 32-Point DC Output Module

Allen-Bradley 1746-OV32 SLC 500 32-Point Digital DC Output Module

Availability: 4 left in stock

DescriptionThe Allen-Bradley 1746-OV32 is a 32-point digital DC output module designed for use with the SLC 500 programmable controller system....

SKU: 1746-OV32

Manufacturer: Allen-Bradley
Product No.: 1746-OV32
Product Type: Digital Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Allen-Bradley 1746-OV32 is a 32-point digital DC output module designed for use with the SLC 500 programmable controller system. As a current-sinking output module, it provides reliable switching for various industrial control applications. This module is engineered to handle a wide range of DC voltages, making it a versatile component for managing field devices such as solenoids, relays, and indicators within an automated control environment.

Features

32-point digital output density for high-capacity I/O requirements.
Current-sinking configuration for standard DC load compatibility.
Wide operating voltage range from 5 to 50 VDC.
Optimized for seamless integration into the SLC 500 chassis backplane.
Compact modular design for efficient panel space utilization.

Technical Specifications

Product Model	1746-OV32
Manufacturer	Allen-Bradley
Module Type	Digital DC Output Module
Number of Outputs	32
Output Type	Current Sinking
Nominal Voltage	24 VDC
Operating Voltage Range	5 - 50 VDC
Current Rating	0.25 A to 0.5 A per output

Installation Guidelines

Ensure the SLC 500 chassis power is disconnected before installing or removing the module.
Verify that the module is fully seated in the chassis slot and secured with the provided mounting screws to ensure proper backplane connection.
Use appropriate shielded cabling for field wiring to minimize electromagnetic interference (EMI).
Maintain proper clearance around the module to allow for adequate ventilation and cooling.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to prevent damage to internal circuitry.

FAQ

What is the primary function of the 1746-OV32?

The 1746-OV32 is a digital output module for the SLC 500 platform, used to control external DC-powered devices by sinking current to the common return.

Is this module compatible with all SLC 500 processors?

Yes, the 1746-OV32 is designed for the standard SLC 500 I/O chassis and is compatible with the SLC 500 processor family, provided the power supply can support the total current draw of the system.

What does current-sinking mean for this module?

Current-sinking means the module provides the path to common (DC negative) for the load. The load is typically connected between the positive voltage source and the module output terminal.
