Allen-Bradley 1756-M03SE ControlLogix 3-Axis SERCOS Module

Allen-Bradley 1756-M03SE ControlLogix 3-Axis SERCOS Interface Module

Availability: 2 left in stock

The Allen-Bradley 1756-M03SE is a ControlLogix SERCOS interface module designed to provide high-speed, digital communication between a ControlLogix controller and...

SKU: 1756-M03SE

Manufacturer: Allen-Bradley
Product No.: 1756-M03SE
Product Type: Motion Control Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Allen-Bradley 1756-M03SE is a ControlLogix SERCOS interface module designed to provide high-speed, digital communication between a ControlLogix controller and up to three servo drives. This module facilitates precise motion control by enabling real-time data exchange over the SERCOS (Serial Real-time Communication System) interface, supporting data rates of 4 Mbps or 8 Mbps.

Features

Supports up to 3 axes of motion control.
Compatible with the ControlLogix platform for seamless system integration.
Selectable SERCOS data rates of 4 Mbps or 8 Mbps.
Occupies a single slot in the ControlLogix chassis.
Low power dissipation of 5.0 W.

Technical Specifications

Product Model	1756-M03SE
Number of Axes	3
SERCOS Data Rate	4 Mbps / 8 Mbps
Current Draw at 5.1V DC	760 mA
Current Draw at 24V DC	2.5 mA
Power Dissipation	5.0 W
Operating Temperature	0 to 60 degC (32 to 140 degF)
Storage Temperature	-40 to 85 degC (-40 to 185 degF)
Relative Humidity	5 to 95% non-condensing
Slot Width	1

Installation Guidelines

Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
The module is designed for installation in any slot of a standard ControlLogix chassis.
Use appropriate ESD precautions when handling the module to prevent damage to sensitive internal components.
Ensure proper grounding of the chassis and shielded cabling for the SERCOS interface to minimize EMI interference.
Maintain adequate clearance around the module to ensure proper airflow and cooling, adhering to the specified operating temperature range.
