Allen-Bradley 1771-IFM 8-Point Analog Input Fast Sensing

Availability: 20 left in stock

Product Overview The Allen-Bradley 1771-IFM serves as a specialized high-speed analog input solution for the legacy PLC-5 platform. This module targets applications...

SKU: 1771-IFM

Manufacturer: Allen Bradley
Product No.: 1771-IFM
Product Type: Analog Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 600g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Allen-Bradley 1771-IFM serves as a specialized high-speed analog input solution for the legacy PLC-5 platform. This module targets applications requiring the capture of low-level millivolt signals from sensors such as strain gauges, pressure transducers, and specialized thermal probes. By providing eight independent channels of fast-response sensing, the 1771-IFM ensures that your control system receives precise data with minimal latency. We supply this unit as 100% Brand New and Original, providing a critical lifecycle extension for plants maintaining 1771 Universal I/O architectures.

Technical Specifications

The 1771-IFM utilizes the PLC-5 backplane for both power and high-speed data transfer. All parameters below utilize standard ASCII formatting.

Specification	Details
Module Type	Fast Millivolt Analog Input
Number of Inputs	8 Point Single-Ended
Backplane Current	0.75 Amp at 5V DC
Application	PLC-5 Universal I/O Chassis
Signal Type	Millivolt (mV) DC
Dimensions	27.9 cm x 5.1 cm x 15.2 cm
Weight	0.6 kg (1.30 lbs)
Cooling	Natural Convection
Origin	USA

Engineering Advantages

Fast Sensing Response: The "Fast" designation indicates a high sampling rate compared to standard analog modules. This allows the 1771-IFM to detect rapid fluctuations in millivolt signals, which is essential for dynamic load monitoring and high-speed pressure transients.
Direct Millivolt Interface: This module eliminates the need for external signal conditioners or transmitters. By wiring sensors directly to the 1771-IFM, you reduce signal path resistance and remove potential points of failure in the circuit.
Seamless PLC-5 Integration: The module slots into any standard 1771 I/O chassis. It communicates via block transfer read (BTR) and block transfer write (BTW) instructions, allowing for easy configuration within RSLogix 5 software environments.
Industrial Hardening: Designed for the rigors of heavy manufacturing, the 1771-IFM resists high-frequency interference. The rugged mechanical assembly ensures stable operation in environments with significant vibration and ambient temperature shifts.

FAQs

Q: Can the 1771-IFM handle standard 4-20mA or 0-10V signals?

A: No. The 1771-IFM is purpose-built for low-level millivolt inputs. For current or higher voltage signals, you must utilize the 1771-IFE or 1771-IFV modules respectively to ensure correct impedance matching and scaling.

Q: Does this module require an external power supply for the inputs?

A: The module itself draws 0.75 Amps directly from the PLC-5 backplane to power its internal circuitry. However, depending on your field device type (e.g., a 4-wire bridge), your sensors may require a separate excitation voltage source.

Q: How do I handle shield grounding for these millivolt signals?

A: For optimal noise rejection, you should ground the cable shields at only one end—typically at the 1771 chassis ground bus. This prevents ground loops that can introduce significant errors into sensitive millivolt measurements.
