Allen-Bradley 2711-T10C8 PanelView 1000 Color HMI Terminal

Allen-Bradley 2711-T10C8 PanelView 1000 Color Touchscreen Terminal

Availability: 0 left in stock

DescriptionThe Allen-Bradley 2711-T10C8 is a PanelView 1000 Standard operator terminal designed for robust industrial HMI applications. This unit features a...

SKU: 2711-T10C8

Manufacturer: Allen-Bradley
Product No.: 2711-T10C8
Product Type: HMI Operator Terminal
Product Origin: USA
Payment:T/T, Western Union
Weight: 3780g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Allen-Bradley 2711-T10C8 is a PanelView 1000 Standard operator terminal designed for robust industrial HMI applications. This unit features a 10.1-inch active-matrix TFT color display with a 640 x 480 VGA resolution, providing a clear interface for monitoring process variables and machine status. It utilizes analog resistive touchscreen technology, allowing for precise interaction with runtime objects.

Features

10.1-inch full-color active-matrix TFT display
Integrated Data Highway Plus (DH+) communication port for legacy PLC integration
RS-232 printer port for alarm and event logging
Supports PanelBuilder32 application development software
384-cell touch matrix (24 columns x 16 rows)
1008 KB non-volatile application memory

Technical Specifications

Model	2711-T10C8
Display Size	10.1 inches
Resolution	640 x 480 pixels (VGA)
Input Voltage	85 to 264 VAC (47-63 Hz)
Communication	Data Highway Plus (DH+)
Memory	1008 KB Application / 310 KB Runtime
Operating Temp	0 degC to +55 degC
Enclosure Rating	NEMA 12, 13, 4X (indoor), IP54, IP65
Weight	3.78 kg

Applications

This terminal is widely utilized in legacy automation environments, including:

Automotive manufacturing (robotics and stamping presses)
Water and wastewater treatment (valve and tank level control)
Pulp, paper, and printing (web tension and fault logging)
Petrochemical refining (batch tracking and temperature monitoring)

Installation Guidelines

Mount the terminal in a NEMA-rated enclosure to maintain IP54/IP65 ingress protection.
Ensure the AC power supply is connected to the removable terminal block; use a small slotted screwdriver and torque screws to manufacturer specifications to prevent arcing.
In Class 1, Division 2 hazardous locations, strictly avoid connecting or disconnecting communication cables or memory cards while the circuit is live.
Maintain adequate clearance around the unit for ventilation to ensure the backlight longevity.
Verify that the DH+ network is properly terminated at both ends of the trunk line to ensure signal integrity.

FAQ

What controllers are compatible with this terminal?

The 2711-T10C8 is specifically designed for integration with legacy Allen-Bradley systems, including PLC-5 and SLC 5/04 processors, via the DH+ network.

What is the purpose of the RS-232 port?

The auxiliary RS-232 port is primarily used for connecting an external printer for alarm and event logging, or for transferring application files from a PC.

How is the application memory managed?

The unit features 1008 KB of non-volatile memory for application storage and 310 KB of runtime memory for active operations, programmed via PanelBuilder32 software.
