330130-085-01-00 Bently Nevada Armored Extension Cable

Bently Nevada 330130-085-01-00 3300 XL Extension Cable

Bently Nevada 330130-085-01-00 3300 XL Extension Cable

Availability: 10 left in stock

The Bently Nevada 330130-085-01-00, also cataloged as the 330130 Extension Cable, operates as a dedicated hardware component for physical RF...

SKU: 330130-085-01-00

Manufacturer: Bently Nevada
Product No.: 330130-085-01-00
Product Type: Proximity Sensors
Product Origin: USA
Payment:T/T, Western Union
Weight: 290g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Bently Nevada 330130-085-01-00, also cataloged as the 330130 Extension Cable, operates as a dedicated hardware component for physical RF signal transmission within 3300 XL 8mm Proximity Transducer System networks.

Suffix Breakdown & Model Matrix

The part number 330130-085-01-00 designates specific physical properties based on the Bently Nevada ordering matrix:

330130: Base model for 3300 XL 8mm Extension Cable.
085: Cable length option designating 8.5 meters (27.9 feet).
01: Connector protector and cable option designating armored cable with a connector protector.
00: Agency approval option indicating no hazardous area approvals are required.

Hardware Specifications

Parameter	Specification
Model	330130-085-01-00
Brand	Bently Nevada
Origin	USA
Cable Length	8.5 meters (27.9 feet)
Cable Construction	Armored coax with connector protector
Shielding	Outer armor sheath over shielded coaxial conductor
System Compatibility	3300 XL 8mm Proximity Transducer Systems
System Total Length	Must form a matched 9.0-meter system with a 0.5-meter probe
Operating Temp	-51 to +177 deg C
Physical Weight	0.034 kg (excluding packaging)
Shipping Weight	2.00 kg

Transducer Calibration & Rotor Dynamics Technical Characteristics

Within Bently Nevada machinery monitoring networks, the 330130 coaxial extension cable serves as a critical component in maintaining matched system impedance. The 3300 XL Proximitor Sensor requires a precise total electrical length of 9.0 meters (comprised of the 0.5-meter probe lead and this 8.5-meter extension cable) to calibrate the eddy-current probe scaling to exactly 7.87 V/mm (200 mV/mil). This accurate impedance matching prevents signal attenuation and cross-talk suppression between adjacent monitoring channels. Accurate system capacitance ensures the sensor validates the physical gap voltage, keeping the target bias operating around a central -10 VDC zone. This precise voltage registration enables the host system to capture micro-level changes in rotor dynamics, including radial vibration and axial thrust position, without signal phase distortion.

Frequently Asked Questions

Q: Can this 8.5-meter extension cable be paired with a 1.0-meter 3300 XL probe?

A: No. The Proximitor sensor is calibrated for a specific total system length of either 5.0 meters or 9.0 meters. Pairing an 8.5-meter extension cable with a 1.0-meter probe creates a 9.5-meter mismatch, which alters system impedance and invalidates the 7.87 V/mm scale factor.

Q: What is the purpose of the integrated connector protector?

A: The connector protector (option 01) mechanically insulates and seals the connection point between the probe lead and the extension cable. It prevents environmental ingress, moisture build-up, and physical grounding of the coaxial shield to the machine casing or conduit.

Field Installation Guidelines

Tightening Torque: Ensure the coaxial connectors are tightened finger-tight plus 1/4 turn using insulated connector wrenches. Do not use standard pliers, which can deform the connection terminals.
Minimum Bend Radius: The armored cable sheath must not be bent to a radius of less than 25.4 mm (1.0 inch) to prevent internal coaxial dielectric degradation and signal reflection anomalies.
Isolation and Grounding: The coaxial connectors must remain electrically isolated from the metallic armor and the machine frame. Use the installed connector protector to insulate the junction.
Conduit Routing: Route the armored cable through dedicated, grounded metal conduit or cable trays separated from high-voltage AC power lines to avoid electromagnetic interference and maintain cross-talk suppression.
