Bently Nevada 990-05-50-03-05 990 Vibration Transmitter

Availability: 10 left in stock

The Bently Nevada 990-05-50-03-05, also cataloged as the 990 Vibration Transmitter, operates as a dedicated hardware component for proximity probe...

SKU: 990-05-50-03-05

Manufacturer: Bently Nevada
Product No.: 990-05-50-03-05
Product Type: Vibration Transmitters
Product Origin: USA
Payment:T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Bently Nevada 990-05-50-03-05, also cataloged as the 990 Vibration Transmitter, operates as a dedicated hardware component for proximity probe signal conditioning and 4-20 mA current loop conversion within machinery protection networks.

Suffix Breakdown & Model Matrix

Option Code	Option Description	Technical Definition
990	Base Model	2-Wire Vibration Transmitter
-05	Full-scale Option	0-5 mils pp (0-125 um pp) relative vibration amplitude range
-50	System Length Option	5.0 meters (16.4 feet) total system length matching probe and cable
-03	Mounting Option	DIN clips and screws integrated for mounting flexibility
-05	Agency Approval Option	CSA Division 2, ATEX Zone 0, ATEX Zone 2, and ABS maritime approvals

Hardware Specifications

Parameter	Specification
Model	990-05-50-03-05
Brand	Bently Nevada
Origin	USA
Product Type	Vibration Transmitters
Input Device	Accepts input from 3300 NSv non-contacting proximity probe and extension cable
Signal Output	4-20 mA DC proportional to relative vibration amplitude
Full-Scale Range	0-5 mils pp (0-125 um pp)
System Length	5.0 meters (16.4 feet)
Mounting Interface	DIN rail clips and surface mounting screws
Environmental Rating	Potted construction for high humidity environments (up to 100% condensing)
Agency Approvals	CSA Division 2, ATEX Zone 0, ATEX Zone 2, ABS maritime
Operating Temp	Standard 990 field transmitter temperature rating
Power Consumption	Loop-powered via output 4-20 mA loop circuit

Gap Voltage Validation (-10 VDC Targets) & Eddy-Current Probe Scaling

The transmitter interfaces directly with a 3300 NSv proximity probe to condition high-frequency eddy-current signals across a calibrated 5.0-meter path. Correct installation requires gap voltage validation via the non-isolated PROX OUT and COM terminals, ensuring a static bias voltage target of -10 VDC at the physical center of the probe linear range. Precise eddy-current probe scaling converts dynamic gap variations caused by shaft motion into an accurate 4-20 mA output signal without loss of amplitude accuracy or phase alignment.

Frequently Asked Questions

Q: How is signal verification performed on this transmitter without disconnecting field wiring?

A: The module incorporates a dedicated test input pin alongside non-isolated PROX OUT and COM terminals, allowing technicians to verify loop current output and monitor raw gap voltage using standard test equipment.

Q: Can this unit withstand high-humidity field environments?

A: Yes, the unit features fully potted internal construction designed to withstand extreme moisture conditions up to 100% condensing humidity.

Q: Is an external Proximitor Sensor required to operate the 3300 NSv probe with this transmitter?

A: No, the transmitter contains an integrated Proximitor Sensor circuit within its potted enclosure, processing raw probe signals directly without secondary external signal conditioners.

Field Installation Guidelines

Mount the transmitter module onto a 35 mm DIN rail using the integrated clips, or secure it directly to a backplate using the mounting screws.
Thread the 3300 NSv proximity probe extension cable onto the coaxial input jack on the transmitter, tightening hand-tight to secure the connection.
Connect a multimeter to the non-isolated PROX OUT and COM terminals, adjusting mechanical probe depth until a static gap voltage of -10 VDC is established.
Route two-wire shielded cable from the 4-20 mA output terminals to the control system analog input channel.
Ground the cable drain wire at a single point on the cabinet grounding bus bar to prevent ground loops and protect against electrical interference.
