Description
The DS3800HIOA1C1E is a specialized printed circuit board designed for the GE Mark IV Speedtronic turbine control system. As a critical component within the Speedtronic architecture, this board facilitates essential signal processing and interface management for industrial turbine regulation. It is engineered to perform in demanding environments such as oil refineries, power generation facilities, and marine propulsion systems, providing reliable signal conditioning to ensure stable turbine operation and prevent costly unplanned downtime.
Features
- System Compatibility: Specifically engineered for the Mark IV Speedtronic control platform.
- Revision Logic: The 1C1E suffix indicates specific hardware iteration, including updated board artwork and components for improved operational resilience.
- Connectivity: Utilizes robust multi-pin edge connectors to ensure high-integrity communication with the system backplane.
- Mounting: Equipped with four factory-drilled mounting holes to provide secure installation within standard control racks, even in high-vibration settings.
Technical Specifications
| Model | DS3800HIOA1C1E |
| Brand | GE Fanuc |
| Series | Mark IV Speedtronic |
| Group | Group 1 |
| Nominal Power | 5.5 W |
| Input Voltage | 5 VDC / 24 VDC (Backplane) |
| Operating Temperature | 0 to 60 deg C |
| Storage Temperature | -40 to 85 deg C |
Installation Guidelines
- Ensure the control system is powered down before inserting or removing the board to prevent electrical damage.
- Handle by the edges or non-conductive surfaces to avoid electrostatic discharge (ESD) damage to sensitive components.
- Ensure the board is firmly seated into the backplane connector before tightening the mounting screws.
- Verify that the rack environment is clean and within the specified temperature range to ensure component longevity.
FAQ
Q: What does the 1C1E suffix represent?
A: The 1C1E suffix denotes the specific revision level of the board, reflecting the firmware, component, and PCB layout versioning used by GE for this model.
Q: Is this board compatible with other Mark series systems?
A: This board is specifically designed for the Mark IV Speedtronic system. It is not intended for use in other generations unless explicitly documented by the manufacturer.
