Description
The ABB DSQC643 (Part Number 3HAC024488-001) is a dedicated panel board assembly designed for integration within the ABB IRC5 robot control cabinet. This circuit board serves as a critical interface component for IRC5 systems featuring flat-door cabinet configurations. It is engineered to maintain reliable communication and signal distribution within the robotic control architecture.
Features
- Official ABB robotics component designed for IRC5 control cabinets.
- Optimized for installation in flat-door cabinet styles.
- Robust PCB construction to withstand industrial environments.
- Direct replacement for 3HAC024488-001/01 assemblies.
Applications
This panel board is specifically utilized in the maintenance and repair of ABB IRC5 robot controllers. It is a standard replacement part for technicians performing hardware upgrades or troubleshooting signal path issues within the control cabinet's interface panel.
Technical Specifications
| Model | DSQC643 |
| Part Number | 3HAC024488-001 |
| Component Type | Panel Board / PCB |
| Compatibility | ABB IRC5 Cabinet (Flat Door) |
| Weight | 0.4 kg |
Installation Guidelines
- Ensure the IRC5 cabinet is fully powered down and locked out (LOTO) before opening the enclosure.
- Use appropriate ESD (electrostatic discharge) protection, such as a grounded wrist strap, when handling the PCB to prevent damage to integrated circuits.
- Verify that the cabinet door type matches the flat-door design requirement for this specific board version.
- Carefully align the board with the mounting standoffs and ensure all ribbon cables or connectors are seated firmly without bending pins.
- Inspect for any debris or loose hardware inside the cabinet before restoring power.
FAQ
Is this board compatible with all IRC5 cabinets?
No, the DSQC643 is specifically designed for IRC5 cabinets equipped with flat doors. Please verify your cabinet configuration before installation.
Does this part include mounting hardware?
The product typically ships as the board assembly. We recommend retaining original mounting screws from the unit being replaced.
