ProSoft PS69-DPS Profibus DPV1 Slave Module

ProSoft PS69-DPS Profibus DPV1 Slave Communication Module

Availability: 2 left in stock

DescriptionThe ProSoft PS69-DPS is a specialized communication interface module designed to provide PROFIBUS DPV1 slave connectivity. Engineered for seamless integration...

SKU: PS69-DPS

Manufacturer: ProSoft
Product No.: PS69-DPS
Product Type: Communication Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 160g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The ProSoft PS69-DPS is a specialized communication interface module designed to provide PROFIBUS DPV1 slave connectivity. Engineered for seamless integration within industrial control environments, this module enables reliable data exchange between a PROFIBUS network and compatible control platforms. It utilizes the integrated ASPC2 communication processor to ensure robust performance in demanding automation applications.

Features

Supports PROFIBUS DPV1 slave functionality for advanced diagnostic and parameterization capabilities.
Integrated ASPC2 architecture ensures consistent communication reliability.
Compatible with 1769 backplane systems, facilitating a single-slot footprint.
RS-485 physical layer interface for standard industrial networking.
High-speed data transfer rates reaching up to 12 Mbps.

Technical Specifications

Model	PS69-DPS
Communication Protocol	PROFIBUS DPV1 Slave
Physical Interface	RS-485
Maximum Data Rate	12 Mbps
Power Requirements	260 mA at +5 VDC
Form Factor	Single-slot 1769 backplane compatible

Installation Guidelines

Ensure the control system is powered down before inserting or removing the module from the backplane.
Verify that the module is fully seated in the 1769 slot to ensure proper communication with the backplane bus.
Use shielded RS-485 cabling to minimize signal interference and maintain data integrity over long distances.
Maintain proper grounding practices for the control cabinet to protect against electromagnetic interference (EMI).
Ensure the ambient operating environment remains within standard industrial temperature and humidity specifications.

FAQ

What is the primary function of the PS69-DPS?
The PS69-DPS acts as a slave device on a PROFIBUS network, allowing the host controller to communicate with other PROFIBUS-enabled field devices.

Is this module compatible with standard 1769 I/O racks?
Yes, the PS69-DPS is specifically designed for use in 1769 backplane environments, occupying a single slot.

Does this module support DPV1 features?
Yes, the module is designed to support PROFIBUS DPV1, which allows for expanded diagnostic data and improved parameterization compared to standard DPV0 protocols.
