Product Details The Yokogawa SB401-10 serves as a vital ESB Bus Interface Slave Module within the CENTUM VP and CS 3000 Distributed...

SKU: SB401-10

Manufacturer: Yokogawa
Product No.: SB401-10
Product Type: ESB Bus Slave Modules
Product Origin: Japan
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Details

The Yokogawa SB401-10 serves as a vital ESB Bus Interface Slave Module within the CENTUM VP and CS 3000 Distributed Control System (DCS) architectures. This module facilitates high-speed, deterministic data exchange between Field Control Stations (FCS) and remote nodes. We provide this component as 100% brand new and original in factory packing, specifically engineered to maintain the backbone of your industrial control network.

Product Overview

The SB401-10 acts as the communication gateway for slave stations on the ESB bus. It bridges the data path between the main controller and remote I/O expansion units, ensuring that process variables and control commands synchronize across the entire DCS network. By providing a stable interface for the system bus, the SB401-10 allows the CENTUM system to manage distributed assets with the same precision as locally connected hardware. This module is essential for large-scale industrial plants that require high-availability, redundant communication links between disparate control components.

Technical Specifications

Attribute	Specification Details
Manufacturer	Yokogawa Electric Corporation
Model Number	SB401-10
System Compatibility	CENTUM VP and CENTUM CS 3000
Function	ESB Bus Interface Slave Module
Communication Speed	100 Mbps (Fast Ethernet)
Bus Interface	PCI-based Station Integration
Connector Type	RJ-45 Ethernet Port
Power Supply	3.3 VDC via Backplane
Current Consumption	2.0 – 2.5 A
Operating Temperature	0°C to +60°C (32°F to 140°F)
Relative Humidity	5% to 95% (Non-condensing)
Condition	New & Original in Factory Packing

Engineering Advantages

Optimized Network Redundancy: The SB401-10 supports Yokogawa’s dual-redundant bus architecture. This design prevents communication loss by automatically rerouting data through the secondary bus path if a primary link failure occurs.
Low-Latency Data Synchronization: The PCI-based architecture allows for rapid data throughput and 100 Mbps communication speeds. This ensures that remote I/O data reaches the Field Control Station without the lag typical of non-deterministic network interfaces.
Industrial Hardening: Engineered for 24/7 continuous operation, the module withstands the thermal and electrical stresses of a factory environment. It maintains signal integrity even in areas subject to significant electromagnetic interference (EMI).
Simplified Hardware Integration: The compact modular design allows for effortless installation into existing control stations. Standard RJ-45 connectors enable the use of CAT5e or higher cabling, reducing the need for specialized or proprietary wiring solutions.
Deterministic Control Backbone: By strictly adhering to the ESB bus protocol, the SB401-10 guarantees that time-critical process data arrives in a predictable sequence, which is a fundamental requirement for safety-critical and high-precision control loops.

FAQs

What is the role of the SB401-10 in an "ESB" configuration?

The SB401-10 operates as a "Slave" interface. It resides in the remote I/O node (or expansion rack) and communicates back to the "Master" interface located in the Field Control Station (FCS). It manages the receipt and transmission of local I/O data across the system bus.

Can I use the SB401-10 in a modern CENTUM VP system?

Yes. While it is a staple of the legacy CS 3000 series, Yokogawa maintains compatibility for the SB401-10 within the CENTUM VP environment, allowing for seamless maintenance and expansion of existing control stations.

Does the module require external power?

No. The SB401-10 draws its required 3.3 VDC directly from the station backplane. This reduces wiring complexity and ensures the module powers up simultaneously with the rest of the station hardware.

What cabling is recommended for the SB401-10?

The module features a standard RJ-45 port and supports 100 Mbps Fast Ethernet speeds. For optimal performance and noise immunity, we recommend using shielded CAT5e or CAT6 cabling, especially in environments with high electrical noise.
