Rockwell 1756-IB32 10-31V DC High Density Input Module

Availability: 20 left in stock

Product Overview The Allen-Bradley 1756-IB32 delivers high-density discrete input capabilities for the ControlLogix platform. This module interfaces 32 separate 24V DC field...

SKU: 1756-IB32

Manufacturer: Allen Bradley
Product No.: 1756-IB32
Product Type: Digital Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 700g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Allen-Bradley 1756-IB32 delivers high-density discrete input capabilities for the ControlLogix platform. This module interfaces 32 separate 24V DC field devices—such as limit switches, proximity sensors, and push buttons—to a single chassis slot. We supply this product as 100% Brand New and Original in factory-sealed packaging, backed by a 12-month factory warranty. It optimizes cabinet space by doubling the input capacity of standard 16-point modules while maintaining rugged industrial performance.

Technical Specifications

Feature	Details
Number of Inputs	32 (Sinking Inputs)
Input Groups	2 Groups (16 Points per Group)
Voltage Range	10–31.2 VDC
Nominal Input Voltage	24 VDC
Backplane Current (5.1V)	120 mA
Backplane Current (24V)	2 mA
Maximum Power Dissipation	6.2 W @ 60 °C
On-State Current (Min)	4.8 mA @ 10 VDC
Off-State Voltage (Max)	5 V
Signal Delay (Typical)	3 ms
Isolation Voltage	250V Continuous (Channel-to-Backplane)
Removable Terminal Block	1756-TBCH or 1756-TBS6H (36-Pin)

Engineering Advantages

Maximize Chassis Utilization: The 32-point high-density architecture allows engineers to scale their systems without purchasing additional chassis or power supplies. This drastically reduces the total footprint of the ControlLogix system.
Enhanced Signal Integrity: The module features 250V continuous isolation between the field-side inputs and the backplane logic. This reinforced barrier prevents ground loops and protects sensitive CPU components from field-side electrical surges.
Flexible Grouping: The 1756-IB32 organizes inputs into two isolated groups of 16. This enables the use of multiple power sources or distinct safety circuits within a single module, simplifying field wiring layouts.
Thermal Efficiency: Despite its high density, the module maintains a manageable thermal profile (21.1 BTU/hr). It operates reliably at temperatures up to 60 °C (140 °F) without requiring specialized cooling, provided standard spacing guidelines are followed.

FAQs

Which Removable Terminal Block (RTB) does the 1756-IB32 require?

The 1756-IB32 utilizes a 36-pin RTB. You must use either the 1756-TBCH (Cage clamp) or the 1756-TBS6H (Spring clamp). Note that the RTB is sold separately from the module.

Does this module support "Sinking" or "Sourcing" field devices?

The 1756-IB32 is a Sinking input module. This means the module provides the path to ground (common) for the current flowing from your sourcing field devices (PNP sensors).

How do I handle the high-density wiring to avoid crosstalk?

We recommend using shielded twisted-pair cabling for high-speed or sensitive signals. Ensure that you dress the 36 wires neatly within the RTB housing to prevent mechanical strain on the connector pins and to maintain clear separation between the two 16-point groups.

Can I replace a 1756-IB16 with a 1756-IB32 to save space?

Yes, but you must update the I/O configuration in your Studio 5000 / RSLogix 5000 software. Furthermore, since the 1756-IB32 uses a 36-pin connector while the IB16 uses a 20-pin connector, you will need to rewire the signals to the correct 36-pin RTB.
