1MRK004810-AB RED670 | ABB | Relion 670 Line Differential IED

1MRK004810-AB RED670 | ABB | Relion 670 Line Differential IED

Availability: 10 left in stock

Product Overview The RED670 (1MRK004810-AB) is a high-performance numerical IED (Intelligent Electronic Device) optimized for the high-speed protection of transmission lines in...

SKU: RED670 1MRK004810-AB

Manufacturer: ABB
Product No.: RED670 1MRK004810-AB
Product Type: Distance Protection Relay
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 3000g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The RED670 (1MRK004810-AB) is a high-performance numerical IED (Intelligent Electronic Device) optimized for the high-speed protection of transmission lines in medium- and high-voltage power networks. As a key component of the ABB Relion 670 series, the RED670 (1MRK004810-AB) provides phase-segregated line differential protection combined with full-scheme distance protection zones. This dual-capability ensures sub-cycle fault detection and isolation, maintaining grid stability during complex disturbances. Engineered for the modern digital substation, it features native support for IEC 61850 communication, enabling deterministic data exchange for pilot-wire and fiber-optic protection schemes while providing comprehensive measurement and monitoring functions for critical infrastructure.

Detailed Technical Specifications

Manufacturer: ABB
Model Designation: RED670
Part Number: 1MRK004810-AB
Product Series: Relion 670 Protection and Control
Device Type: Distance and Line Differential Protection Relay
Protection Logic: 5-zone distance protection (phase-to-phase and phase-to-ground), line differential protection, directional overcurrent, and breaker failure logic
Fault Location Accuracy: Precision fault locator (provides distance in km, miles, or percentage of line length)
Measurement Precision: High-accuracy monitoring of active/reactive power, energy, frequency, voltage, and current
Rated Current Input: 1 A or 5 A (Selectable via software/hardware configuration)
Rated Voltage Input: Up to 110 V AC (Standard VT secondary circuit)
Nominal Frequency: 50 / 60 Hz (Adaptive tracking)
Auxiliary Power Supply: Wide-range universal 24–250 V DC or 48–240 V AC
Binary I/O Configuration: Multiple programmable digital input and output channels for status feedback and trip signaling
Communication Protocols: IEC 61850-8-1 (Ed. 1 & 2), IEC 60870-5-103, Modbus RTU/TCP, DNP3
Time Synchronization: SNTP, IRIG-B, and GPS (IEEE 1588 PTP supported)
Interface: Local HMI with high-resolution LCD, keypad, and programmable LEDs
Operating Temperature: -25°C to +70°C
Dimensions (WxHxD): Approximately 190 mm x 170 mm x 200 mm
Weight: 3.0 kg
Standards Compliance: IEC 60255 series, CE, UL Listed
