ABB NTDI01 Digital I/O Termination Unit

ABB 1SAP224100R0001 AC500 PLC PROFIBUS DP Module

ABB 1SAP224100R0001 AC500 PLC PROFIBUS DP Module

Availability: 10 left in stock

Product Overview The ABB CI541-DP (1SAP224100R0001) serves as a high-versatility PROFIBUS DP slave interface module within the AC500 PLC ecosystem....

SKU: CI541-DP 1SAP224100R0001

Manufacturer: ABB
Product No.: CI541-DP 1SAP224100R0001
Product Type: AC500 PLC Series
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 134g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The ABB CI541-DP (1SAP224100R0001) serves as a high-versatility PROFIBUS DP slave interface module within the AC500 PLC ecosystem. This "Mixed I/O" powerhouse combines analog and digital signal processing into a single decentralized node. It handles a diverse range of field signals, including Voltage (U), Current (I), and RTD temperature sensors, alongside standard 24V DC digital points. By integrating these functions into one compact unit, the CI541-DP reduces hardware footprints in distributed control architectures. We supply this module as 100% Brand New and Original, ensuring high-speed data synchronization and robust fieldbus connectivity for your automation network.

Technical Specifications

Attribute	Specification Details
Model Number	CI541-DP
Product ID	1SAP224100R0001
Protocol	PROFIBUS DP (Slave)
Analog Inputs (AI)	4 Channels (U, I, RTD supported)
Analog Outputs (AO)	2 Channels (U, I supported)
Digital Inputs (DI)	8 Channels (24V DC)
Digital Outputs (DO)	8 Channels (24V DC, 0.5A)
Baud Rate	9.6 kbps to 12 Mbps
Net Weight	0.134 kg
Dimensions (WxHxD)	67.5 mm x 76 mm x 62 mm
Operating Temp	–25°C to +60°C

Engineering Advantages

The CI541-DP addresses the complexity of modern field installations by consolidating multiple signal types into a single PROFIBUS station.

Multi-Signal Consolidation: This module eliminates the need for separate analog and digital expansion cards. By supporting Voltage, Current, and RTD inputs on the same device, it simplifies the mapping of complex process sensors like thermocouples and pressure transmitters.
High-Speed Bus Performance: The CI541-DP supports PROFIBUS baud rates up to 12 Mbps. This ensures that analog values and digital states reach the AC500 controller with minimal latency, which is essential for closed-loop PID control and safety interlocking.
Galvanic Interference Shielding: Integrated galvanic isolation separates the PROFIBUS network from the internal module logic. This protection prevents ground loops and electrical transients from disrupting communication, a vital feature for noisy environments like turbine halls and pump stations.
Optimized Cabinet Efficiency: The 67.5 mm width maximizes DIN-rail density. Despite its small profile, the module handles up to 0.5A per digital output, allowing it to actuate valves and relays directly without additional signal conditioning.

FAQs

Can the CI541-DP AI channels handle PT100 temperature sensors?

Yes. The 4 Analog Input channels support RTD configurations. You can wire PT100 or PT1000 sensors directly to the module to capture precise temperature data for process monitoring.
Does the digital output section require an external power supply?

Yes. You must provide a 24V DC supply to power the module logic and the 8 digital output channels. Each output supports a load of 0.5A, sufficient for most industrial actuators.
Is this module compatible with non-ABB PROFIBUS Masters?

As a standard PROFIBUS DP Slave, the CI541-DP interfaces with any PLC or DCS controller that complies with the PROFIBUS DP protocol standard, though it is optimized for the ABB AC500 series.
In what condition is the unit shipped?

We guarantee the CI541-DP 1SAP224100R0001 is 100% Brand New and Original. It arrives in factory-sealed packing (Package Level 1: 84 x 72 x 71 mm) to ensure maximum reliability and longevity in the field.
