Product Overview The ABB 560PSR00 (Part Number: 1KGT026500R0001) functions as the primary power source for RTU560 subrack systems, including the 560MPR03 and 560SFR02. Engineered for utility-grade reliability,...

SKU: 560PSR00 1KGT026500R0001

Manufacturer: ABB
Product No.: 560PSR00 1KGT026500R0001
Product Type: Substation Automation
Product Origin: USA
Payment:T/T, Western Union
Weight: 425g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The ABB 560PSR00 (Part Number: 1KGT026500R0001) functions as the primary power source for RTU560 subrack systems, including the 560MPR03 and 560SFR02. Engineered for utility-grade reliability, this module converts wide-range DC inputs into stabilized 5 VDC and 24 VDC outputs to drive embedded controllers, communication interfaces, and I/O modules. It excels in substation automation and grid control environments where uninterrupted power is mandatory. We provide this unit as 100% Brand New and Original, ensuring high-availability performance for mission-critical electrical infrastructure.

Technical Specifications

Parameter	Specification
Model Number	560PSR00
Product ID	1KGT026500R0001
Input Voltage Range	24 V DC to 60 V DC
Output Voltage 1	5 V DC (Regulated)
Output Voltage 2	24 V DC (Regulated)
Efficiency	≥ 90%
Redundancy	Supports N+1 Parallel Configuration
Protection	Overcurrent, Short-circuit, Thermal Shutdown
Operating Temperature	–25°C to +70°C
Mounting	RTU560 Subrack Slot
Dimensions	20.5 cm × 14.7 cm × 5.4 cm
Net Weight	0.425 kg

Engineering Advantages

Redundant High-Availability Architecture: The 560PSR00 supports parallel operation. By installing multiple units in an N+1 configuration, you ensure the RTU560 system remains fully operational even if one power supply module fails. This prevents costly downtime in remote monitoring sites.
Wide DC Input Versatility: The unit accepts an input range of 24 VDC to 60 VDC. This flexibility allows seamless integration with standard station batteries, solar-charged DC buses, and diverse industrial backup systems common in grid controls.
Dual Regulated Outputs: A single 560PSR00 module delivers both 5V and 24V rails simultaneously. The 5V output powers the internal logic of the bus, while the 24V rail drives the field-level I/O and communication ports, simplifying the subrack's internal power distribution.
Harsh Environment Resilience: ABB builds the 560PSR00 to withstand extreme temperatures ranging from -25°C to +70°C. The robust solid-state construction and thermal protection circuits maintain stable voltage delivery even in unconditioned outdoor cabinets or high-heat substation environments.
Hot-Swappable Maintenance: When configured in a redundant setup, you can replace a faulty 560PSR00 module while the system is live. This "hot-swap" capability eliminates the need to shut down the RTU560 controller during maintenance cycles.

FAQs

Does the 560PSR00 1KGT026500R0001 support AC input?

The 1KGT026500R0001 version primarily supports a 24–60 VDC input range for RTU560 subracks. Always verify your subrack's backplane requirements and the specific variant (some PSR series support 100-240 VAC) before installation to ensure electrical compatibility.

How do I confirm the redundancy status of the module?

The module features front-panel LED indicators. These LEDs monitor the status of the input voltage and both regulated output rails. In a redundant configuration, the system controller monitors these signals to notify the operator if one PSU loses its output.

Is this unit compatible with Symphony Plus systems?

While the 560PSR00 is specifically designed for RTU560 hardware, it often integrates into larger ABB automation architectures like Symphony Plus via the RTU's communication links. However, the physical mounting is restricted to RTU560-compatible subracks (560MPR03/560SFR02).

What is the benefit of the 90% efficiency rating?

High efficiency reduces internal heat dissipation within the subrack. This extends the lifespan of adjacent I/O modules and CPUs by preventing localized hotspots, which is critical for long-term reliability in sealed or non-ventilated enclosures.
