Description
The ABB NDNA-02 is a fieldbus adapter module designed to provide seamless connectivity between ABB drives and a DeviceNet industrial network. This module facilitates high-speed communication, allowing for the integration of drive parameters, control signals, and status monitoring into a centralized DeviceNet control architecture. As a dedicated communication interface, it enables efficient data exchange between the drive and the PLC or master controller.
Features
- Provides DeviceNet fieldbus connectivity for ABB drive systems.
- Supports standard DeviceNet protocol communication for industrial automation.
- Compact design for integration within the drive control section.
- Reliable data transfer for drive control, monitoring, and parameter configuration.
- Operating voltage: 24VDC.
- Power consumption: 3W.
Technical Specifications
| Model | NDNA-02 |
| Order Code | 3ADT220104R0005 |
| Spare Model | NDNA-02-KIT (3AUA489002B5047) |
| Protocol | DeviceNet |
| Supply Voltage | 24VDC |
| Power Consumption | 3W |
| Manufacturer | ABB |
Installation Guidelines
- Ensure the drive is completely powered down and the DC bus capacitors have discharged before installing or removing the NDNA-02 module.
- Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to internal electronic components.
- Insert the module into the designated option slot on the drive control board, ensuring proper alignment with the connector pins.
- Secure the module using the provided mounting hardware to ensure vibration resistance and proper grounding.
- Use shielded twisted-pair cable for the DeviceNet network connection to minimize EMI interference.
- Verify that the network termination resistors are correctly installed at both ends of the DeviceNet trunk line.
FAQ
Is the NDNA-02 module still in production?
No, the NDNA-02 has been discontinued by the manufacturer. Please refer to the NDNA-02-KIT (3AUA489002B5047) for replacement or spare part requirements.
What is the primary function of this module?
The NDNA-02 acts as a communication gateway, allowing an ABB drive to function as a slave device on a DeviceNet network, enabling remote control and monitoring via the fieldbus.
