ABB IMCIS22 Bailey DCS Communication Board | 6644130F1

ABB IMCIS22 Bailey DCS Communication Board | 6644130F1

Availability: 10 left in stock

Product Overview The ABB IMCIS22 functions as an advanced Control I/O Slave Module within the INFI 90® and Symphony Harmony distributed control system (DCS) architecture. This...

SKU: IMCIS22

Manufacturer: ABB
Product No.: IMCIS22
Product Type: Control I/O Slave Units
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The ABB IMCIS22 functions as an advanced Control I/O Slave Module within the INFI 90® and Symphony Harmony distributed control system (DCS) architecture. This module facilitates high-speed, multi-protocol communication between local controllers, operator consoles, and external supervisory networks. Compared to legacy IMCIS models, the IMCIS22 incorporates enhanced processing logic to support redundant data paths and faster throughput. It serves as a vital bridge in modern industrial plants, translating internal DCS variables into standardized Ethernet TCP/IP or Modbus protocols for plant-wide data integration and real-time monitoring.

Technical Specifications

The IMCIS22 utilizes a multi-rail power architecture and ruggedized circuitry to ensure deterministic performance in mission-critical environments.

Attribute	Technical Data
Manufacturer	ABB (Bailey Controls)
Model Number	IMCIS22
Product Code	6644130F1
Module Type	Control I/O Slave Module / Communication Interface
System Compatibility	INFI 90® / Symphony Harmony DCS
Operating Voltages	+5V, +/-15V, 24V DC
Power Consumption	3.5 VA (approx. 10 W total)
Protocols Supported	Ethernet TCP/IP, Modbus, Infi-Net
Operating Temp	-20°C to +70°C
Isolation	Galvanic isolation (Communication to Control circuits)
Weight	0.2 Kg (Net) / 1.5 Kg (Shipping)
Dimensions	10 × 4.5 × 12 cm

Engineering Advantages

Superior Protocol Versatility: The IMCIS22 natively handles Ethernet TCP/IP, Modbus, and Infi-Net protocols. This multi-standard support allows engineers to integrate the INFI 90 system with modern SCADA packages and third-party PLCs without requiring expensive third-party gateways.
Deterministic High-Speed Throughput: Optimized processing hardware reduces packet latency across the control network. The IMCIS22 ensures that operator commands and process alarms transmit instantly, maintaining the sub-millisecond response times required for turbine control and petrochemical safety systems.
Multi-Rail Power Reliability: The module operates across +5V, +/-15V, and 24V DC rails. This dedicated power architecture separates logic processing from communication signal driving, preventing voltage fluctuations on the network lines from affecting the module’s core stability.
Galvanic Noise Rejection: Industrial environments generate significant electromagnetic interference. The IMCIS22 utilizes robust galvanic isolation to block ground loops and shield internal DCS logic from external transients originating on external Ethernet or Modbus cable runs.
Seamless Hot-Swappable Maintenance: The modular design allows technicians to replace the IMCIS22 while the DCS rack remains energized. This hot-swappable capability ensures that communication maintenance on one segment does not necessitate a complete process shutdown.
100% Brand New Condition: We deliver only original, factory-sealed ABB IMCIS22 units. This guarantees that internal capacitors, voltage regulators, and communication transceivers possess their full factory-rated lifespan, securing the long-term uptime of your DCS backbone.

FAQs

Q: How does the IMCIS22 differ from the earlier IMCIS02 model?

A: The IMCIS22 provides significantly higher data throughput and improved support for modern Ethernet-based redundancy. It also features optimized internal diagnostics that report communication health more accurately to the Harmony operator stations.

Q: Does the IMCIS22 require a specific firmware version on the Harmony Controller?

A: The IMCIS22 is designed for backward compatibility; however, full utilization of its enhanced speed and protocol features may require a minimum firmware revision for your IMMFP or BRC controllers. Always check your system configuration via ABB Composer.

Q: Can I use this module to bridge INFI 90 data to a modern cloud-based SCADA?

A: Yes. By utilizing its Ethernet TCP/IP and Modbus capabilities, the IMCIS22 serves as the primary hardware interface for exporting real-time DCS data to external servers or enterprise-level management systems.

Q: What are the installation requirements for the 6644130F1?

A: The module slides directly into a standard slot within an ABB Module Mounting Unit (MMU). It connects to the backplane via a standard multi-pin connector, which supplies the necessary +5V, +/-15V, and 24V power rails.
